| Price | $4,500 ~ $6,000 / set |
| MOQ | 1 set |
| Delivery Time | 7 work days |
| Brand | RUNNING |
| Place of Origin | QINGDAO CHINA |
| Certification | CE |
| Model Number | ZLJ-800*830 |
| Packaging Details | Plywood case (Fumigation free) |
| Payment Terms | T/T, L/C |
| Supply Ability | 50 sets/month |
| Usage | Splicing vulcanizing conveyor belt | Place of Origin | QINGDAO CHINA |
| Packaging Details | Plywood case (Fumigation free) | Model Number | ZLJ-800*830 |
| Supply Ability | 50 sets/month | Certification | CE |
| Brand Name | RUNNING | Payment Terms | T/T, L/C |
| Overall size | 1280*830*630mm | Price | $4,500 ~ $6,000 / set |
| Delivery Time | 7 work days | Minimum Order Quantity | 1 set |
| Heating power | 11.2kw | Machine weight | 650kg |
| Applied belt width | 800mm or customized | Heating method | Electric heating |
Rubber Conveyor Belt Splicing Vulcanizing Machine with 800mm Width
Usage:
Conveyor
belt
splicing
Vulcanizing
is
the
process
of
splicing
together
two
pieces
of
conveyor
belt.
Usually,
this
is
done
to
either
elongate
the
original
conveyor
belt
or
to
repair
a
torn
or
damaged
conveyor
belt.
Machine specification of conveyor belt splicing vulcanizing machine:
| Specifications of ZLJ series Belt Joint Vulcanizing Machine | D=22 degree | |||||||
|
Model Number |
Max Belt width(mm) |
Max
Splice
Length Width E(mm) |
Press Dimensions |
Power (kw) |
Weight(kg) | |||
| A(mm) | C(mm) | B(mm) | External dimension (LxWxH)(mm) | |||||
| ZLJ-650 | 650 | 500 | 535 | 790 | 870 | 1080x730x630 | 6.1 | 280 |
| 650 | 670 | 707 | 790 | 870 | 1080x900x630 | 8.2 | 300 | |
| 650 | 750 | 790 | 790 | 870 | 1080x980x630 | 9.1 | 320 | |
| 650 | 830 | 872 | 790 | 870 | 1080x1050x630 | 10.1 | 380 | |
| 650 | 1000 | 1045 | 790 | 870 | 1080x1220x630 | 12.2 | 410 | |
| ZLJ-800 | 800 | 500 | 535 | 940 | 1020 | 1280x730x630 | 7.1 | 380 |
| 800 | 670 | 707 | 940 | 1020 | 1280x900x630 | 9.6 | 410 | |
| 800 | 750 | 790 | 940 | 1020 | 1280x980x630 | 10.7 | 420 | |
| 800 | 830 | 872 | 940 | 1020 | 1280x1050x630 | 11.9 | 460 | |
| 800 | 1000 | 1045 | 940 | 1020 | 1280x1220x630 | 14.3 | 490 | |
| ZLJ-1000 | 1000 | 500 | 535 | 1140 | 1220 | 1480x730x630 | 8.5 | 420 |
| 1000 | 670 | 707 | 1140 | 1220 | 1480x900x630 | 11.4 | 500 | |
| 1000 | 750 | 790 | 1140 | 1220 | 1480x980x630 | 12.8 | 520 | |
| 1000 | 830 | 872 | 1140 | 1220 | 1480x1050x630 | 14.2 | 550 | |
| 1000 | 1000 | 1045 | 1140 | 1220 | 1480x1220x630 | 17.1 | 590 | |
| ZLJ-1200 | 1200 | 500 | 535 | 1340 | 1420 | 1680x730x630 | 9.9 | 510 |
| 1200 | 670 | 707 | 1340 | 1420 | 1680x900x630 | 13.3 | 550 | |
| 1200 | 750 | 790 | 1340 | 1420 | 1680x980x630 | 14.9 | 590 | |
| 1200 | 830 | 872 | 1340 | 1420 | 1680x1050x630 | 16.5 | 610 | |
| 1200 | 1000 | 1045 | 1340 | 1420 | 1680x1220x630 | 19.1 | 650 | |
| ZLJ-1400 | 1400 | 500 | 535 | 1540 | 1620 | 1880x730x730 | 11.3 | 690 |
| 1400 | 670 | 707 | 1540 | 1620 | 1880x900x730 | 15.2 | 720 | |
| 1400 | 750 | 790 | 1540 | 1620 | 1880x980x730 | 17.0 | 750 | |
| 1400 | 830 | 872 | 1540 | 1620 | 1880x1050x730 | 18.8 | 780 | |
| 1400 | 1000 | 1045 | 1540 | 1620 | 1880x1220x730 | 22.7 | 850 | |
| ZLJ-1600 | 1600 | 500 | 535 | 1740 | 1820 | 2080x730x730 | 12.7 | 830 |
| 1600 | 670 | 707 | 1740 | 1820 | 2080x900x730 | 17.1 | 880 | |
| 1600 | 750 | 790 | 1740 | 1820 | 2080x980x730 | 19.1 | 920 | |
| 1600 | 830 | 872 | 1740 | 1820 | 2080x1050x730 | 21.2 | 940 | |
| 1600 | 1000 | 1045 | 1740 | 1820 | 2080x1220x730 | 25.5 | 1010 | |
| ZLJ-1800 | 1800 | 500 | 535 | 1940 | 2020 | 2280x730x730 | 14.1 | 880 |
| 1800 | 670 | 707 | 1940 | 2020 | 2280x900x730 | 19.0 | 920 | |
| 1800 | 750 | 790 | 1940 | 2020 | 2280x980x730 | 21.2 | 950 | |
| 1800 | 830 | 872 | 1940 | 2020 | 2280x1050x730 | 23.5 | 1050 | |
| 1800 | 1000 | 1045 | 1940 | 2020 | 2280x1220x730 | 28.3 | 1150 | |
| ZLJ-2000 | 2000 | 500 | 535 | 2140 | 2220 | 2480x730x820 | 15.5 | 920 |
| 2000 | 670 | 707 | 2140 | 2220 | 2480x900x820 | 20.8 | 1060 | |
| 2000 | 750 | 790 | 2140 | 2220 | 2480x980x820 | 23.3 | 1130 | |
| 2000 | 830 | 872 | 2140 | 2220 | 2480x1050x820 | 25.8 | 1240 | |
| 2000 | 1000 | 1045 | 2140 | 2220 | 2480x1220x820 | 31.1 | 1370 | |
| ZLJ-2200 | 2200 | 500 | 535 | 2340 | 2420 | 2680x730x820 | 16.9 | 1020 |
| 2200 | 670 | 707 | 2340 | 2420 | 2680x900x820 | 22.7 | 1190 | |
| 2200 | 750 | 790 | 2340 | 2420 | 2680x980x820 | 25.4 | 1310 | |
| 2200 | 830 | 872 | 2340 | 2420 | 2680x1050x820 | 28.1 | 1460 | |
| 2200 | 1000 | 1045 | 2340 | 2420 | 2680x1220x820 | 33.9 | 1590 | |
Our conveyor belt splicing vulcanizing machine use rubber coated heating blanket, it has fast heating speed and is lightweight.
For pressurizing system of conveyor belt splicing vulcanizing machine, we adopt water pump + Water pressure bag, the pressure bag is made of rubber, it has advantages of lightweight, balanced pressure, lower leakage risk and no rusting risk.
Package of conveyor belt splicing vulcanizing machine:
For more machine details pelase feel free to contact us!
