| Price | Deliberations |
| MOQ | Deliberations |
| Delivery Time | 5-8 work days |
| Brand | Airui |
| Place of Origin | Shandong，China |
| Certification | ISO/TS16949 |
| Model Number | AC00100101 |
| Packaging Details | 1. Hot shrink poly per set/box and ten boxes in one carton. 2. Pallet packing. 3. As your requirements |
| Payment Terms | L/C, T/T |
| Supply Ability | 20000 Set/Sets per Month |
| Place of Origin | Shandong，China | Tube | 100 mm square |
| Use | Trailer Parts | Size | unbrake axle |
| Packaging Details | 1. Hot shrink poly per set/box and ten boxes in one carton. 2. Pallet packing. 3. As your requirements | Bolts | unbrake axle |
| Material | Iron | Model Number | AC00100101 |
| Supply Ability | 20000 Set/Sets per Month | Certification | ISO/TS16949 |
| Brand Name | Airui | Payment Terms | L/C, T/T |
| Price | Deliberations | Delivery Time | 5-8 work days |
| Length | Customer Model | Quality | 100% Guaranteed |
| Minimum Order Quantity | Deliberations | Max Payload | 8000-15000 lbs |
15000 Lbs 100 Mm Round Tube Straight Unbrake Free Length Trailer Axle
How do trailer axles work?
Purpose of Trailer Wheel Hubs
Tires are attached with studs to the hub assembly. The hub assembly then fits on the axle, which connects the tire component to the rest of the car. Because the wheel hub is the bridge between the tire and the entire vehicle, if one of its parts breaks down, it creates a ripple effect.
| NO. | Description | QTY | option 1 | option 2 | option 3 |
| 1 | axle shaft | 1 | 127*8mm round tube | 50mm round tube | |
| 2 | spring seat | 2 | AC00100104 | ||
| 3 | Mounting plate | 2 | AC00100103 | ||
| 4 | Forge spindle | 2 | AC00100102 | AT01200103 | |
| 5 | 12.25" brake plate | 2 | AZ001/D35/071 electric | AZ069/070 hydraulic | |
| 6 | bolt, washer, nut | 8,10,14 | AC00100501/2/3 | ||
| 7 | oil seal | 2 | AC00100400 | ||
| 8 | inner bearing | 2 | 387A/382A | ||
| 9 | hub drum | 2 | AC00100300 | ||
| 10 | wheel retaining ring | 2 | AC00100900 | ||
| 11 | wheel nut | 16 | AC00100304 | ||
| 12 | outer bearing | 2 | 22580/25520 | ||
| 13 | castle nut | 2 | AC00100701 | ||
| 14 | split pin | 2 | AC00100702 | ||
| 15 | Oil cap | 2 | AC00100200 |
Features:
Axle Beam Acts as part of your trailer Suspension for hauling loads.
Great for replacing an old axle or bent damaged axle on your trailer
Made of High Strength Steel
Underslung axle design: spring pads are welded to the underside of the axle for mounting leaf springs.
Spring pads are pre-welded on the trailer axle for your convenience.
The 5 lug Hub Drums & Electric Brakes are assembled on the axle and 5 lug idler hubs on other axle with the bearings, seals, pre-greased, fully assembled for simple installation on your trailer.
Great for Utility Trailer Axle, Boat Trailer Axle, Car Haulers Trailer Axle, ATV Trailer Axle, Lawn & Landscape Trailer Axle, Motorcycle Trailer Axle, BBQ Pit Trailer Axle, Cargo Trailer Axle, Enclosed Trailer Axle, RV Trailer Axle & More
