12*15cm 5 Twist Metal Gabion Mesh Basket Galfan Fine Mesh Metals Gabion Baskets

Price	negotiable
MOQ	100PCS
Delivery Time	10-25days
Brand	HBGB
Place of Origin	China
Certification	ISO 9001
Model Number	GB-002
Packaging Details	compacted before packaging, in bundle
Payment Terms	L/C, T/T, Western Union
Supply Ability	1000 pcs per day

Product Details

Product Specification

Usage	protect and support seawall, slope, road, bridge, reservoirs	Place of Origin	China
Packaging Details	compacted before packaging, in bundle	Hole shape	hexagonal
Material	Q195 wire	Zinc coating	more than 270g/m2
Model Number	GB-002	Aperture	68cm, 810cm, 1012cm, 1215cm
Supply Ability	1000 pcs per day	Certification	ISO 9001
Surface treatment	hot dipped galvanized, PE coated, galfan	Brand Name	HBGB
Payment Terms	L/C, T/T, Western Union	Tie wire	2.2 mm
selvage wire	3.4 mm	Price	negotiable
Delivery Time	10-25days	Product name	Gabion Mesh Basket
Net wire	popular 2.7mm	Minimum Order Quantity	100PCS

Product Description

Metal gabion basket mesh filled with stone or rock for river wall

Gabion Mesh Basket Introduction:

Gabion basket is also called gabion box, gabion wall, gabion cage, hexagonal gabion, gabion retaining wall and so on. It is a large cage made by hexagonal wire netting, it can be filled by stones, the wire material is high quality galvanized carbon steel, it is strong enough to protect road, river wall or forward operating bases.

Gabion length could be adjusted by add diaphragms each meter.

Gabion Mesh Basket Raw Material:

Product Name	Gabion
Hole Type	Hexagonal
Production process	Three twist / Five twist
Material	GI wire,PVC coated wire,galfan wire
Wire Diameter	2.0mm-4.0mm
Hole Size	60×80mm,80×100mm,100×120mm,120×150mm
Gabion Size	2m×1m×0.5m,2m×1m×1m,3m×1m×0.5m,3m×1m×1m 4m×1m×0.5m,4m×1m×1m,Other sizes can be customized.

Gabion Mesh Basket Usage:

It is used for the scour protection of rivers, dikes and seawalls, as well as cage for the closure of reservoirs and rivers. The most serious disaster of the river is that the water scours the Bank of the river and causes the flood, which leads to a lot of loss of life and property and a lot of soil erosion. Therefore, when dealing with the above problems, the application of the grid ecological grid structure becomes one of the best solutions, which can make the river bed and bank permanent protection.

Gabion Mesh Basket Specifications:

Mesh Size	Galvanized Gabion( Dia.mm)	PVC Gabion (Inside Dia/Outside Dia.mm)	Max Wide Cut
60x80mm	Φ2.0-2.8	Φ2.0/3.0-2.8/3.8	4300
80x100mm	Φ2.2-3.2	Φ2.2/3.2-3.0/4.0	4300
80x120mm	Φ2.2-3.2	Φ2.2/3.2-3.0/4.0	4300
100x120mm	Φ2.4-3.5	Φ2.4/3.4-3.2/4.2	4300
100x150mm	Φ2.4-3.5	Φ2.4/3.4-3.2/4.2	4300
120x150mm	Φ2.7-4.0	Φ2.7/3.7-3.5/4.5	4300
