| Price | Negotiable |
| MOQ | 3 pieces |
| Delivery Time | 3-8 Working Days |
| Brand | AIRSUSTECH |
| Place of Origin | Guangzhou, China |
| Certification | ISO/TS16949:2009 |
| Model Number | F-160-2 |
| Packaging Details | Strong Carton Box or as Customers Requirement |
| Payment Terms | T/T, Western Union,Paypal or Others |
| Supply Ability | 1000pcs/week |
| Origin | China | Shape | double Convoluted |
| Bumper Block | Without | Packaging Details | Strong Carton Box or as Customers Requirement |
| HS Code | 8708809000 | Port | Huangpu, China |
| Design High | 98 mm | Load Type | Compression |
| Max Diameter | 220 mm | Trademark | Neutral |
| Supply Ability | 1000pcs/week | Function | Reduce Vibration |
| Transport Package | Cartons | Minimum Order Quantity | 3 pieces |
| Minimum Height | 53 mm | Stroke | 70 mm |
| Usage | Industrial press machine | Place of Origin | Guangzhou, China |
| Warranty | One Year | Vibration Frequency | 2 |
| Color | Black | Specification | 24*24*12cm |
| Material | Rubber | Model Number | F-160-2 |
| Certification | ISO/TS16949:2009 | Brand Name | AIRSUSTECH |
| Payment Terms | T/T, Western Union,Paypal or Others | Pressure Ability | 0.2-0.88 MPa |
| N.W. | 1.80 Kg | Delivery Time | 3-8 Working Days |
| Production Process | Vulcanization |
S-160
items
Detailed
Parameter
Table:
| GUOMAT NO. | Reference No. | Hight H(mm) | Commonly Maximum Stroke(mm) | The Largest Diameter When Compressed(mm) | ||
| Design High(mm) | Maximum High(mm) | Minimum Height(mm) | ||||
| F-160-1 | S-160-1 | 72 | 102 | 40 | ±25 | 220 |
| F-160-2 | S-160-2 | 98 | 148 | 53 | ±35 | 220 |
| F-160-3 | S-160-3 | 152 | 227 | 82 | ±53 | 220 |
| F-160-4 | S-160-4 | 206 | 306 | 111 | ±70 | 220 |
| GUOMAT NO. | Reference No. | Standard Height,Internal Pressure 0.49 M pa When The General Value | Using Maximum Internal Pressure (M pa) | Internal Pressure (M pa) | ||||
| Effective Area (Cm2) | Volume(L) | Load (K n) | Dynamic Spring Parameters (N/Min) | Vibration Frequency (Hz) | ||||
| F-160-1 | S-160-1 | 200 | 1.9 | 9.8 | 636 | 3 | 0.69 | 2.9-3.9 |
| F-160-2 | S-160-2 | 200 | 2.1 | 9.8 | 255 | 2.5 | 0.88 | 2.9-3.9 |
| F-160-3 | S-160-3 | 200 | 3.4 | 9.8 | 157 | 2 | 0.88 | 2.9-3.9 |
| F-160-4 | S-160-4 | 200 | 4.7 | 9.8 | 118 | 1.7 | 0.88 | 2.9-3.9 |
Packaging
Information:
Net
Weight:1.85
KG
Gross
Weight:2.35
KG
Package
Size:110mm*220mm*220mm
S-160-2R
air
spring
may
fits
below
items
Bronzing
machine
Shock
absorption
Roller
tension
Quick
lock
device
Reel
tension
Machine
isolation
Scissor
lift
Mechanical
hopper
vibration
and
damping
treatment
stop
Direct
force
Platform
lift
Short
stroke
mechanical
linkage
GUOMAT
Has Punch
Press
Air
Spring
Cushion
/Air
Shock
Absorber Part
NO.
Below:
| GUOMAT Part NO. | Japan YOKOHAMA Reference No. | Japan YOKOHAMA Reference No. | GUOMAT Part NO. | Japan YOKOHAMA Reference No. | Japan YOKOHAMA Reference No. |
| F-600-1 | F-600-R1 | 600-1r | F-240-4 | F-240-R4 | 240-4r |
| F-600-2 | F-600-R2 | 600-2r | F-240-3 | F-240-R3 | 240-3r |
| F-600-3 | F-600-R3 | 600-3r | F-240-2 | F-240-R2 | 240-2r |
| F-600-4 | F-600-R4 | 600-4r | F-240-1 | F-240-R1 | 240-1r |
| F-600-5 | F-600-R5 | 600-5r | F-220-4 | F-220-R4 | 220-4r |
| F-550-2 | F-550-R2 | 550-2r | F-220-3 | F-220-R3 | 220-3r |
| F-550-3 | F-550-R3 | 550-3r | F-220-2 | F-220-R2 | 220-2r |
| F-500-2 | F-500-R2 | 500-2r | F-200-2 | F-200-R2 | 200-2r |
| F-500-3 | F-500-R3 | 500-3r | F-200-3 | F-200-R3 | 200-3r |
| F-500-4 | F-500-R4 | 500-4r | F-200-4 | F-200-R4 | 200-4r |
| F-500-5 | F-500-R5 | 500-5r | F-160-1 | F-160-R1 | 160-1r |
| F-450-1 | F-450-R1 | 450-1r | F-160-2 | F-160-R2 | 160-2r |
| F-450-2 | F-450-R2 | 450-2r | F-160-3 | F-160-R3 | 160-3r |
| F-450-3 | F-450-R3 | 450-3r | F-160-4 | F-160-R4 | 160-4r |
| F-450-4 | F-450-R4 | 450-4r | F-120-4 | F-120-R4 | 120-4r |
| F-450-5 | F-450-R5 | 450-5r | F-120-3 | F-120-R3 | 120-3r |
| F-400-2 | F-400-R2 | 400-2r | F-120-2 | F-120-R2 | 120-2r |
| F-400-3 | F-400-R3 | 400-3r | F-100-4 | F-100-R4 | 100-4r |
| F-400-4 | F-400-R4 | 400-4r | F-90-3 | F-90-R3 | 90-3r |
| F-400-5 | F-400-R5 | 400-5r | F-90-2 | F-90-R2 | 90-2r |
| F-350-1 | F-350-R1 | 350-1r | F-90-1 | F-90-R1 | 90-1r |
| F-350-2 | F-350-R2 | 350-2r | F-300-1 | F-300-R1 | 300-1r |
| F-350-3 | F-350-R3 | 350-3r | F-300-2 | F-300-R2 | 300-2r |
| F-350-4 | F-350-R4 | 350-4r | F-300-3 | F-300-R3 | 300-3r |
| F-300-4 | F-300-R4 | 300-4r |
