| Price | Negotiable |
| MOQ | 3 pieces |
| Delivery Time | 3-8 Working Days |
| Brand | AIRSUSTECH |
| Place of Origin | Guangzhou, China |
| Certification | ISO/TS16949:2009 |
| Model Number | F-500-3 |
| Packaging Details | Strong Carton Box or as Customers Requirement |
| Payment Terms | T/T, Western Union,Paypal or Others |
| Supply Ability | 1000pcs/week |
| Origin | China | Shape | Convoluted |
| Bumper Block | Without | Packaging Details | Strong Carton Box or as Customers Requirement |
| HS Code | 8708809000 | Port | Huangpu, China |
| Design High | 160 mm | Load Type | Compression |
| Max Diameter | 600 mm | Trademark | Neutral |
| Supply Ability | 1000pcs/week | Function | Reduce Vibration |
| Transport Package | Cartons | Minimum Order Quantity | 3 pieces |
| Minimum Height | 90 mm | Stroke | 136 mm |
| Usage | Industrial | Place of Origin | Guangzhou, China |
| Warranty | One Year | Vibration Frequency | 1.8 |
| Color | Black | Specification | 55*55*20 cm |
| Material | Rubber | Model Number | F-500-3 |
| Certification | ISO/TS16949:2009 | Brand Name | AIRSUSTECH |
| Payment Terms | T/T, Western Union,Paypal or Others | Pressure Ability | 0.2-0.88 MPa |
| N.W. | 11.5 Kg | Model NO. | F-500-3 |
| Delivery Time | 3-8 Working Days | Production Process | Vulcanization |
AIRSUSTECH F-500-3 Cross other OE:
AIRSUSTECH Part No.: F-500-3
Yokohama Part No.: S-500-3
Yokohama Part No.: S500-3
Yokohama Part No.: S-500-3R
Yokohama Part No.: S500-3R
AIRSUSTECH F-500-3 Weight and Packing Size:
Net Weight:11.5 KG
Gross Weight:13.5 KG
Package Size:173 mm*550mm*550mm
Compressed
height:100mm
Maximum
Height:220mm
Full
stroke:120mm
Working
medium:water,
air
Working
pressure:<
0.7Mpa
Burst
pressure:>
1.6Mpa
Endurance
cycle:>
10"
Temperature:-35℃
~+60℃
This item F-500-3 Detailed Parameter Table: replaces Yokohama S-500-3R
| AIRSUSTECH NO. | Reference No. | Hight H(mm) | Commonly Maximum Stroke(mm) | The Largest Diameter When Compressed(mm) | ||
| Design High(mm) | Maximum High(mm) | Minimum Height(mm) | ||||
| F-500-3 | S-500-3 | 160 | 270 | 90 | ±68 | 560 |
| Standard Height,Internal Pressure 0.49 M pa When The General Value | Using Maximum Internal Pressure (M pa) | Internal Pressure (M pa) | ||||
| Effective Area (Cm2) | Volume(L) | Load (K n) | Dynamic Spring Parameters (N/Min) | Vibration Frequency (Hz) | ||
| 1965 | 30.3 | 96.3 | 1255 | 1.8 | 0.69 | 3.9-4.9 |
Lots of industria equipment use this air spring:
S-500-3R Yokohama Air Spring fits for the following Punch press:
AIRSUSTECH S-500-3R air spring production of the air spring has the following advantages:
1, product quality, Thailand import natural rubber, the core technology in Germany
2, With the same price on the market, AIRSUSTECH S-500-3R optimal quality. With the same quality of products, AIRSUSTECH S-500-3R has lowest price.
3, cars, trucks, buses and industrial air spring has production, fully meet the customers' different requirements.
4, AIRSUSTECH S-500-3R spell price, not only do the brand.
5, more than 10 years of production technology, products cover all over the world.
6, have dealers around the world, the first response to all customer requirements.
