1250Kva Cast Resin Dry Type Transformers Isolation 480V IEEE ANSI Standard
Nov 11, 2025
1 views
Chat Now
WINLEY produces high-quality cast resin dry-type transformers up to 10 MVA and 35 kV. Manufactured in a facility equipped with advanced vacuum casting systems and a range of molds, our transformers meet diverse application needs. The 3-phase 1250 kVA model offers robust copper windings, silicon steel core, AN/AF cooling, Dyn1 vector group, and class F insulation with temperature-control protection and cooling fans. Housed in a coated steel NEMA 3R enclosure, it delivers reliable performance with low losses and industry-standard design in compliance with IEEE/ANSI C57.12.00.
We would like to invite you to visit Winley’s official website to learn more about our products and solutions:
https://www.winley-electric.com/
