| Price | Factory Price |
| MOQ | 1 Set |
| Delivery Time | 30-45 work days |
| Brand | Lycorrugated |
| Place of Origin | China |
| Certification | CE, ISO,TUV, SGS |
| Model Number | AP-1600BSG |
| Packaging Details | Case |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Supply Ability | 300 Sets per year |
| Place of Origin | China | Packaging Details | Case |
| MODEL | 1600BSG Flatbed Die Cutter | Maximum sheet size | 1100X1600mm |
| Model Number | AP-1600BSG | Supply Ability | 300 Sets per year |
| Certification | CE, ISO,TUV, SGS | Miximum cutting size | 1080X600mm |
| Brand Name | Lycorrugated | Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Gripper size | 15(±5)mm | Minimum sheet size | 450X600mm |
| Applicable thickness of corugated board | 1.5-9mm | Maximum operational pressure | 350tons |
| Price | Factory Price | Delivery Time | 30-45 work days |
| Minimum Order Quantity | 1 Set |
High Precision Carton Box Machine Automatic Platen Flatbed Die Cutter
Machine Specification:
| MODEL | 1600BSG |
| Maximum sheet size | 1100X1600mm |
| Minimum sheet size | 450X600mm |
| Miximum cutting size | 1080X600mm |
| Gripper size | 15(±5)mm |
| Inside size | 1120X1620mm |
| Maximum operational pressure | 350tons |
| Applicable thickness of corugated board | 1.5-9mm |
| Maximum speed | 5750i.p.h |
| Required power supply | 34KW |
| Net weight of machine | 32tons |
Features in perfromance:
1, Exclusively for corrugated board with non-stop bottom feeder.
2, Accurate registration from E flute to double-wall AB flute.
3, Complete stripping by a paif of male and female stripping dies and automatic grip edge waste removal.
4, High producitivity is available for short run and long run jog.
5, Safety devices protect operators and dual safety system stops machien run even power is cut off.
6, All tooling set from exterior of machine.
