| Price | Factory Price |
| MOQ | 1 Piece |
| Delivery Time | Negotiable |
| Brand | LY Corrugated |
| Place of Origin | China |
| Certification | CE、ISO、TUV、SGS |
| Payment Terms | L/C, D/A, D/P, T/T |
| Brand Name | LY Corrugated | Payment Terms | L/C, D/A, D/P, T/T |
| Max. Printing Size (mm) | 1600*3560 | Accuracy | +-0.5mm |
| Place of Origin | China | Minimum Feed Size | 200*435 |
| Price | Factory Price | Minimum Order Quantity | 1 Piece |
| Product Name | Flexo Printer Slotter Die Cutter | Specification | 5000 KG |
| Maximum Feed Size | 1600*3600 | Certification | CE、ISO、TUV、SGS |
Two Color Flexo Printer For Carton Box Packing Box Corrugated Cardboard
| Model | T-GC618 | T-GC920 | T-GC924 | T-GC1224 | T-GC1228 | T-GC1428 | T-GC1628 | T-GC1632 | T-GC1636 |
| Max. Speed (pcs/min) | 350 | 300 | 300 | 250 | 230 | 220 | 180 | 180 | 160 |
| Max. Feeding Size (mm) | 600×1800 | 900×2000 | 900×2400 | 1200×2400 | 1200×2800 | 1400×2800 | 1600×2800 | 1600×3200 | 1600×3600 |
| Min. Feeding Size(mm) | 200×435 | 270×600 | 270×600 | 320×600 | 320×600 | 365×600 | 450×600 | 450×600 | 450×600 |
| Skip Feeding(mm) | 800×1800 | 1200×2000 | 1200×2400 | 1500×2400 | 1500×2800 | 1700×2800 | 1900×2800 | 1900×3200 | 1900×3600 |
| Max. Printing Size (mm) | 600×1760 | 900×1960 | 900×2360 | 1200×2360 | 1200×2760 | 1400×2760 | 1600×2760 | 1600×3160 | 1600×3560 |
| Min. Slotting(L:mm) | 180×55× 180×55 | 240×65× 240×65 | 240×65× 240×65 | 260×65× 260×65 | 260×65× 260×65 | 260×65× 260×65 | 260×65× 260×65 | 260×65× 260×65 | 260×65× 260×65 |
| Min. Slotting (R: mm) | 110×110× 110×110 | 130×130× 130×130 | 130×130× 130×130 | 130×130× 130×130 | 130×130× 130×130 | 130×130× 130×130 | 130×130× 130×130 | 130×130× 130×130 | 130×130× 130×130 |
| Max. Slotting Depth (mm) | 200 | 250 | 250 | 300 | 300 | 350 | 400 | 400 | 400 |
Flexo Printer
Continuous
or
jump
feed
can
be
used
with
counters.
The
leading
edge
feeder
with
electric
feeding
stroke
can
adjust
and
reduce
the
pressure
of
the
drawing
roll.
Original imported SUN Lead Edge Feeder to ensure long-term feeding accuracy and stability.
Multi-row brush and antistatic system to keep the cardboard clean before entering the printer unit to ensure printing quality.
When the unit is not completely closed and locked, the main motor is protected and will not start.
