Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V
China Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V for sale
China Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V for sale
  1. China Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V for sale
  2. China Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V for sale
  3. China Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V for sale

Lengthen Type Machines Used In Making Corrugated Boxes Overlapping DC24V

Price US$19500 - US$23000 / Set
MOQ 1 Set
Delivery Time 30-45 days
Brand Lycorrugated
Place of Origin Guangdong,China
Certification CE, ISO, SGS,TUV
Model Number Innov350
Packaging Details Case
Payment Terms L/C, T/T
Supply Ability 800PCS per year

Product Details

Product Specification

Place of Origin Guangdong,China Packaging Details Case
Product Auto Splicer Specification 1.8-2.5 Meter
Model Number Innov350 Supply Ability 800PCS per year
Certification CE, ISO, SGS,TUV Remarks(configuration) Taiwan Open Loop Control System
Brand Name Lycorrugated Payment Terms L/C, T/T
Price US$19500 - US$23000 / Set Delivery Time 30-45 days
Working Speed 250m/min Minimum Order Quantity 1 Set
Model Innov350 I type Application Corrugated Cardboard Production Line

Product Description

Servo Motor Control Corrugator Splicer For Corrugated Cardboard Production Line





Standard Configuration:

  • Lengthen type can be customized, with paper pulling motor in different models.
  • Splice type: overlapping.
  • Width: The maximum paper width is 2550mm.
  • Base paper weight: 50g~350g/m2, high gram and heavy duty can be customized.
  • Time for completion of paper splicing reaction: about 1 second.
  • Air source: dry and clean air source with a minimum of 0.6MPa.
  • Power source:380V,50Hz,20A.
  • Control power supply: DC24V.
  • Paper Brake: Pneumatic brake/magnetic powder brake.



Model

Double Lap Open Loop System

Innov350 I type

Specification 1.8-2.5 Meter
Technical Parameter 250m/min
Remarks(configuration) Taiwan Open Loop Control System
Application Corrugated Cardboard Production Line
