| Price | Negotiable |
| MOQ | 50 EA |
| Delivery Time | 30 days |
| Brand | BOMCO |
| Place of Origin | China |
| Certification | API 7K |
| Model Number | F-800 |
| Packaging Details | Wooden Box |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 500 EA Per Month |
| Place of Origin | China | Support | OEM |
| Size | 6-1/2” | Packaging Details | Wooden Box |
| Product Name | Piston | Material | Polyurethane |
| Model Number | F-800 | Supply Ability | 500 EA Per Month |
| Pressure | 7500Psi | Certification | API 7K |
| Brand Name | BOMCO | Payment Terms | L/C, T/T, Western Union |
| Industry | Oil Drilling Mud Pump | Delivery Time | 30 days |
| Minimum Order Quantity | 50 EA |
Mud Pump Piston For BOMCOF-800 Mud Pump Piston Assembly
Product Feature
Piston assembly is one of the main parts of the hydraulic end system of the mud pump, and also one of the wearing parts in drilling work. The
discharge pressure of the mud pump is generated by the reciprocating linear motion of the piston assembly in the piston. Piston assembly
consists of piston core, rubber skin, circlip, pressure plate, etc.
Piston assembly consists of piston core, rubber skin, circlip, pressure plate, etc. The material of the piston core is 42CrMo, and the material of the
piston rubber is nitrile rubber or polyurethane rubber
The piston and the cylinder liner (some have no cylinder liner and are directly connected to the inner wall of the liquid cylinder) form a pair of
dynamic seals, and the sealing elements are assembled on the piston. Through the reciprocating motion of the piston, the volume in the working
chamber is alternately changed, and the pumping, suction and discharge processes are realized with the help of the pump valve. Therefore, it is
required that the piston must have: ① good sealing; ② sufficient strength and rigidity; ③ the connection and positioning of the piston body, the
piston rod, the piston ring, etc. should be firm and reliable.
Has excellent oil resistance and wear resistance. The working temperature is not higher than 120℃, and it is suitable for oil-based mud with a
working pressure below 35Mpa and a working environment with high sand content.
Supply Brand
BOMCO: F-500,F-800,F-1000,F-1300,F-1600,F-1600HL,F-2200HL
HONGHUA:HHF-500,HHF-1000,HHF-1300,HHF-1600,HHF-1600HL,HHF-2200HL
RONGSHENG:RS-F500,RS-F800,RS-F1000,RS-F1300,RS-F1600
LS:3NB-1300C, 3NB-1000, 3NB-1000C,3NB-800
ITECO:T-500,T-800,T-1000,T-1600
Oil WELL:A-350-PT, A-650-PT,A-850-PT, A-1100-PT, A-1400-PT, A-1700-PT
WEATHERFORD:MP-5, MP-8, MP-10, MP-13, MP-16
NATIONAL: 7-P-50, 8-P-80, 9-P-100, 10-P-130, 12-P-160, 14-P-220, C-250,C-350, K-380, K-500-A, K-700
EMSCO:F-350,F-500,F-650,F-800,F-1000,FA-1300,FA-1600,FB-1300,FB-1600,FC-1600, FC-2200,FD-1000, FD-1600
GARDNER DENVER:PZ-7, PZ-8, PZ-9,PZ-10,PZ-11
