| Price | Negotiable |
| MOQ | 1 |
| Delivery Time | Negotiable |
| Brand | GLM |
| Place of Origin | China |
| Certification | ASME, PED and GB |
| Model Number | CAP |
| Packaging Details | wooden box and iron shelf or as percustomers requirement |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 50000 |
| Place of Origin | China | Keywords | Vessel Caps |
| Size | Customized Size | Packaging Details | wooden box and iron shelf or as percustomers requirement |
| Head Shape | Ellipsoidal,Hemispherical,Flat | Material | MILD STEEL; MS |
| Model Number | CAP | Supply Ability | 50000 |
| Certification | ASME, PED and GB | Name | Pressure Vessel Dished Head |
| Brand Name | GLM | Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Minimum Order Quantity | 1 | Head Code | Pressure Vessels Elliptical Head |
| Super Duplex Dished Ends | Manufacturers,Suppliers,Exporters | Finishing | Bright,Hot Rolled,Cold Rolled |
The elliptical head is also known as the elliptical head. The elliptical head is a head composed of two parts: a rotating elliptical sphere and a cylindrical straight section. The elliptical head with the ratio of the major axis to the minor axis of the revolving elliptical sphere generatrix is 2.0, and is customarily called the standard elliptical head. The mechanical properties of the elliptical head are second only to the hemispherical head, but better than the dish-shaped head.
It can answer delicate demands for metals with its raw material stocks and strong connections for long years. According to ASME norms, execution of accurate, controlled and certificated production is most important feature of Wuhan linmei to make difference from others. The dished heads that were manufactured in international norms with cold and hot processing methods are delivered in recorded high-quality program. The dished heads are manufactured in complete or partial and in thickness of 2 mm to 100 mm, and they are subject to quality program which is certified and specified in all stages including shipment. Wuhan linmei is one of the leading company of global market in terms of business capacity and sensitivity in section-tube bendings and plate bendings. Wuhan linmei is an important brand which makes delivery worldwide in all business fields in terms of big capacity, rapid delivery and product quality.
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
FAQ:
1. What’s the information should I provide when inquiry?
Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.
2. what are surface treatment of the product?
Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.
3. How do you ensure the quality of products?
Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.
4. Can you help us matching related products?
Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
