| Price | USD200- 2167/ PC |
| MOQ | 1 PC |
| Delivery Time | 5- 8 work days |
| Brand | Jovi |
| Place of Origin | China |
| Certification | CE |
| Model Number | 1-CF-15 |
| Packaging Details | Wrapped in kraft paper, then packed in wooden case. Size according to lead glass size, usually 5 pcs per case. |
| Payment Terms | L/ C, T/ T, Western Union |
| Supply Ability | 3000PCS per month |
| Place of Origin | China | Shape | Circle, Square and Heteromorphic |
| Size | From 200* 300 to 2400* 1200mm | Packaging Details | Wrapped in kraft paper, then packed in wooden case. Size according to lead glass size, usually 5 pcs per case. |
| Color | Transparent | Model Number | 1-CF-15 |
| Lead Equivalent | 4.4mmpb | Supply Ability | 3000PCS per month |
| Certification | CE | Brand Name | Jovi |
| Payment Terms | L/ C, T/ T, Western Union | Thickness | 20mm |
| Function | Xray Protection | Packing | Wooden Case |
| Price | USD200- 2167/ PC | Delivery Time | 5- 8 work days |
| Minimum Order Quantity | 1 PC |
20mm Thickness CT Room Transparent Radiation Protection Lead Glass
Quick Detail:
· Standard Size from 200*300mm to 1200*2400mm
· Thickness 8/ 10/ 12/ 15/ 18/ 20/ 23/ 25mm
· Lead equivalent 1.7/ 2.1/ 2.6/ 3.3/ 3.96/ 4.4/ 5.8/ 6.71mmpb
· Different material of frame can be provided
· CE Certificate
Notices:
1. Lead glass is a brittle material with a large proportion, so it must be handled gently when it is moved.
2. When installation, the glass must be mismatched with the wall protection material to prevent radiation
leakage at the joint.
3. As lead glass materials are rich in lead and barium, lead glass is easy to be contaminated by acid and base,
and is not easy to be installed or stored in a sour or humid environment.
4. The surface of lead glass is more easily scratched than that of ordinary glass and should be handled
with care.
Application:
Lead glass is mainly used in the manufacturing of optical instruments, art vessels, etc, while also known
as medical X- ray
radiation-proof lead glass plate in the medical field, used for diagnostic X- ray machine rooms, CT, ECT,
PET, ct- pet and other
machine rooms, as well as observation Windows on the protective screen of protective doors.
Specification:
| 8mm | 10mm | 12mm | 15mm | 18mm | 20mm | 25mm | |
| ( 1.7mmpb) | ( 2.1mmpb) | ( 2.6mmpb) | ( 3.3 mmpb) | ( 3.96 mmpb) | ( 4.4 mmpb) | ( 6.71 mmpb) | |
| 200* 300 | 200* 300* 8 | 200* 300* 10 | 200* 300* 12 | 200* 300* 15 | 200* 300* 18 | 200* 300* 20 | - |
| 300* 400 | 300* 400* 8 | 300* 400* 10 | 300* 400* 12 | 300* 400* 15 | 300* 400* 18 | 300* 400* 20 | - |
| 400* 600 | 400* 600* 8 | 400* 600* 10 | 400* 600* 12 | 400* 600* 15 | 400* 600* 18 | 400* 600* 20 | - |
| 600* 800 | 600* 800* 8 | 600* 800* 10 | 600* 800* 12 | 600* 800* 15 | 600* 800* 18 | 600* 800* 20 | - |
| 600* 900 | 600* 900* 8 | 600* 900* 10 | 600* 900* 12 | 600* 900* 15 | 600* 900* 18 | 600* 900* 20 | - |
| 1000* 800 | 1000* 800* 8 | 1000* 800* 10 | 1000* 800* 12 | 1000* 800* 15 | 1000* 800* 18 | 1000* 800* 20 | 1000* 800* 25 |
| 1200* 800 | 1200* 800* 8 | 1200* 800* 10 | 1200* 800* 12 | 1200* 800* 15 | 1200* 800* 18 | 1200* 800* 20 | 1200* 800* 25 |
| 1200* 900 | 1200* 900* 8 | 1200* 900* 10 | 1200* 900* 12 | 1200* 900* 15 | 1200* 900* 18 | 1200* 900* 20 | 1200* 900* 25 |
| 1200* 1000 | 1200* 1000* 8 | 1200* 1000* 10 | 1200* 1000* 12 | 1200* 1000* 15 | 1200* 1000* 18 | 1200* 1000* 20 | 1200* 1000* 25 |
| 1200* 1200 | - | 1200* 1200* 10 | 1200* 1200* 12 | 1200* 1200* 15 | 1200* 1200* 18 | 1200* 1200* 20 | 1200* 1200* 25 |
| 1500* 900 | - | 1500* 900* 10 | 1500* 900* 12 | 1500* 900* 15 | 1500* 900* 18 | 1500* 900* 20 | 1500* 900* 25 |
| 1500* 1000 | - | 1500* 1000* 10 | 1500* 1000* 12 | 1500* 1000* 15 | 1500* 1000* 18 | 1500* 1000* 20 | 1500* 1000* 25 |
| 1500* 1200 | - | 1500* 1200* 10 | 1500* 1200* 12 | 1500* 1200* 15 | 1500* 1200* 18 | 1500* 1200* 20 | 1500* 1200* 25 |
| 1600* 1000 | - | 1600* 1000* 10 | 1600* 1000* 12 | 1600* 1000* 15 | 1600* 1000* 18 | 1600* 1000* 20 | 1600* 1000* 25 |
| 1600* 1200 | - | 1600* 1200* 10 | 1600* 1200* 12 | 1600* 1200* 15 | 1600* 1200* 18 | 1600* 1200* 20 | 1600* 1200* 25 |
| 1800* 1000 | - | 1800* 1000* 10 | 1800* 1000* 12 | 1800* 1000* 15 | 1800* 1000* 18 | 1800* 1000* 20 | 1800* 1000* 25 |
| 1800* 1200 | - | 1800* 1200* 10 | 1800* 1200* 12 | 1800* 1200* 15 | 1800* 1200* 18 | 1800* 1200* 20 | 1800* 1200* 25 |
| 2000* 1000 | - | 2000* 1000* 10 | 2000* 1000* 12 | 2000* 1000* 15 | 2000* 1000* 18 | 2000* 1000* 20 | 2000* 1000* 25 |
| 2000* 1200 | - | 2000* 1200* 10 | 2000* 1200* 12 | 2000* 1200* 15 | 2000* 1200* 18 | 2000* 1200* 20 | 2000* 1200* 25 |
| 2400* 1200 | - | 2400* 1200* 10 | 2400* 1200* 12 | 2400* 1200* 15 | 2400* 1200* 18 | 2400* 1200* 20 | 2400* 1200* 25 |
FAQ:
20mm Thickness CT Room Transparent Radiation Protection Lead Glass
Q1. What is your MOQ of lead glass?
A: 1 Pc is ok.
Q2. What about the lead time?
A: Usually 5- 8 work days.
Q3. How do you ship the cargo in usual?
A: Ship by Air and Sea, also by express is ok if small size.
Q4. Can I order the size mixed?
A: Yes of course.
