| Price | $130/pc-$380/pc |
| MOQ | 5 pc |
| Delivery Time | within 10-14 wroking days after receiving payment |
| Brand | Jovi |
| Place of Origin | China |
| Certification | CE |
| Model Number | 1-CF-4 |
| Packaging Details | in piece and in wooden case |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 2000 pcs per month |
| Usage | MRI RF Room Air Vent Installation | Frame | with or without frame |
| Place of Origin | China | Shape | Rectangular or Circular shape |
| Packaging Details | in piece and in wooden case | Product Name | Stainless Steel Honeycomb Waveguide Air Vents with or without Flanges |
| Standard Size of honeycomb | 300mm*600mm*25mm*4.8mm and Customized size | Material | Stainless Steel |
| Model Number | 1-CF-4 | Supply Ability | 2000 pcs per month |
| Certification | CE | MOQ | 5 pcs |
| Brand Name | Jovi | Payment Terms | L/C, T/T, Western Union |
| Packing | Wooden case | Price | $130/pc-$380/pc |
| Delivery Time | within 10-14 wroking days after receiving payment | Minimum Order Quantity | 5 pc |
Brass Steel Honeycomb Filter Core Vent Waveguide Tube Customized Size Shielded MRI RF Room Installation
Quick Detail :
1. Brass Honeycomb with/without frame
2. Stainless Steel Honeycomb Filter
3. Airflow System Honeycomb Vent
4. Stainless Steel waveguide tube
5. Brass Waveguide tube
Description:
The largest vent size honeycomb vent we can provide is 600mm*900mm,if you need bigger size than it,
it must be jointing bu two or more pieces vent.For 12.5mm thickness model,the largest size is 600mm*600mm,
for 3.2mm cell diameter model,the largest size is 600mm*600mm.
As for the honeycomb, we can offer with frame or without frame honeycomb .
<
| Technical Parameter | ||||
| Cell Diameter : | 4.80mm | |||
| Core Thickness : | 25.00mm | |||
| Frequency Band | Attenuation | |||
| 100KHz | >100dB | |||
| 1MHz-10MHz | >100dB | |||
| 10MHz-30MHz | >100dB | |||
| 3MHz-1G Hz | >100dB | |||
| 1GHz-10GHz | >100dB | |||
| Available Thickness | ||||
| 12.5mm | 25mm | 50mm | ||
| Available Material | ||||
| Steel | Brass | Copper | ||
| Available Size | ||||
| The largest vent size is 600mm*900mm | ||||
Tin Plated Steel / Brass Honeycomb Filter Vent Picture:
Application :
The honeycomb filter and Waveguide product can be well used MRI RF Room, EMC EMI Room installation.
FAQ:
1. Can we get a product sample?
Yes, we can offer sample to you.
2. As for the honeycomb, what materials can you offer ?
We can offer brass / stainless steel/ tin plated steel materials....
3. What is delivery time?
Within 7-10 working days after payment.
