| Price | $10,000 ~ $12,000 / set |
| MOQ | 1 set |
| Delivery Time | 7 work days |
| Brand | RUNNING |
| Place of Origin | QINGDAO CHINA |
| Certification | CE |
| Model Number | ZLJ-1600*830 |
| Packaging Details | Plywood case (Fumigation free) |
| Payment Terms | T/T, L/C |
| Supply Ability | 50 set/month |
| Usage | conveyor belt jointing | Place of Origin | QINGDAO CHINA |
| Packaging Details | Plywood case (Fumigation free) | Model Number | ZLJ-1600*830 |
| Supply Ability | 50 set/month | Certification | CE |
| Brand Name | RUNNING | Payment Terms | T/T, L/C |
| Heating plate size | 1830*830mm | Overall size | 2140*830*800mm |
| Price | $10,000 ~ $12,000 / set | Delivery Time | 7 work days |
| Minimum Order Quantity | 1 set | Heating power | 21kw |
| Machine weight | 1300kg | Applied belt width | 1600mm or customized |
Steel Cord Conveyor Belt Hot Vulcanization Jointing Machine with 1600mm width
Hot vulcanization jointing method:
Hot vulcanization jointing is heated and cured under pressure with a vulcanizing press. This process takes several hours. And the belt can only be used after the splice has cooled down.
Hot vulcanization pays attention to the quality of the belt: the material of the conveyor belt, the formula, the thickness of the covering layer, the manufacturing process of the belt (temperature, time, pressure) and the performance of the processing equipment. Of course, good vulcanization also requires a team of professional workers and a good vulcanizing machine.
Machine specification of conveyor belt hot vulcanization jointing machine:
| Model | Applied Width(mm) | Motor power | Dimension(LxWxH)(mm) | Weight(KG) |
| ZLJ-800x830 | 800 | 11.2 | 1280x830x630 | 650 |
| ZLJ-1000x830 | 1000 | 14.1 | 1480x830x630 | 700 |
| ZLJ-1200x830 | 1200 | 16.5 | 1680x830x710 | 900 |
| ZLJ-1400x830 | 1400 | 18.6 | 1930x830x760 | 1100 |
| ZLJ-1600x830 | 1600 | 21.1 | 2140x830x800 | 1320 |
| ZLJ-1800x830 | 1800 | 23.3 | 2300x830x850 | 1480 |
| ZLJ-2000x830 | 2000 | 25.6 | 2600x830x950 | 1860 |
The strength after splicing / jointing :
The hot vulcanization jointing is equivalent to 60%-80% of the strength of the conveyor belt itself. ( Jointing with cold viscose is equivalent to 40%-55% of the strength of the conveyor belt itself; The buckle (mechanical joint) connection is only 28%-45%.)
The heating element of conveyor belt jointing machine is made of rubber coated resistance heating wire. Compare with ordinary heater, it's more stable and faster heating speed.
The pressurizing element - Water pressure bladder is made of rubber, compared with ordinary metal pressure board, it has more balanced pressure, no rusting risk, lower leakage rish and longer service life.
Shipping package of conveyor belt jointing machine:
There is a lot of other machines for your choice, please feel free to contact us if you need more machine details.
