| Price | $9500 ~ $ 10500 / set |
| MOQ | 1 set |
| Delivery Time | 7 working days |
| Brand | RUNNING |
| Place of Origin | QINGDAO CHINA |
| Certification | CE |
| Model Number | ZLJ/LBD-1600*850 |
| Packaging Details | Plywood case (Fumigation free) |
| Payment Terms | T/T, L/C |
| Supply Ability | 50sets/month |
| Usage | conveyor belt splicer | Place of Origin | QINGDAO CHINA |
| Heating plate | 1830*850mm | Packaging Details | Plywood case (Fumigation free) |
| Stucture | Aluminum alloy beam | Belt width | Max. 1600mm or customized |
| Model Number | ZLJ/LBD-1600*850 | Supply Ability | 50sets/month |
| Pressurize method | Water pump | Certification | CE |
| Brand Name | RUNNING | Payment Terms | T/T, L/C |
| Price | $9500 ~ $ 10500 / set | Delivery Time | 7 working days |
| Minimum Order Quantity | 1 set | Heating method | Electricity |
Lightweight Steel Cord 1600mm Rubber Conveyor Belt Joint Splicer Machine
Application:
Conveyor belt joint splicer is used for joining together two pieces of conveyor belt. Usually, this is done to either elongate the original conveyor belt or to repair a torn or damaged conveyor belt.
Specification of Conveyor Belt Joint Splicer:
| Model | Applied Width(mm) | Motor power | Dimension(LxWxH)(mm) | Weight(KG) |
| ZLJ-800x830 | 800 | 11.2 | 1280x830x630 | 650 |
| ZLJ-1000x830 | 1000 | 14.1 | 1480x830x630 | 700 |
| ZLJ-1200x830 | 1200 | 16.5 | 1680x830x710 | 900 |
| ZLJ-1400x830 | 1400 | 18.6 | 1930x830x760 | 1100 |
| ZLJ-1600x830 | 1600 | 21.1 | 2140x830x800 | 1320 |
| ZLJ-1800x830 | 1800 | 23.3 | 2300x830x850 | 1480 |
| ZLJ-2000x830 | 2000 | 25.6 | 2600x830x950 | 1860 |
ZLJ conveyor belt vulcanizing machines can be used by one or multiple combinations according to the joint length of the belt. The main configuration of a single vulcanizing machine is as following:
| Name | Amount |
| Host machine | 1 set |
| Ratchet wrench | 2 piece |
| steel pad | 1 set |
| Clamping device | 1 set |
| Electric control box | 1 set |
| Power cable | 1 root |
| Control cable | 2 root |
| Thermal resistance | 2 pieces |
| QL electric water pump | 1 set |
| SD Hand pressure pump (Optional) | 1 set |
| Pressure pipe | 2 root |
| Water cooling system (Optional) | 1 set |
Shipping package of conveyor belt joint splicer machine:
