Mini-type DVI Fiber Optic Extender with external stereo audio

Price Negotiated
MOQ 1pcs
Delivery Time 3-12working days
Brand E-link
Place of Origin China
Certification ISO9001, CE, FCC, RoHS
Model Number LNK-MDF100
Packaging Details standard export package
Payment Terms T/T,PayPal
Supply Ability 1000pcs/mouth

Product Details

Product Specification

Temperature Operating: -20℃ ~ +70℃ Place of Origin China
Maximum data rate 6.75Gbps Dimension (LxWxH) 80 x 40 x 20 (mm)
Packaging Details standard export package Maximum pixel clock 165MHz
Model Number LNK-MDF100 Supply Ability 1000pcs/mouth
Certification ISO9001, CE, FCC, RoHS Wavelength 850nm/1310nm
Brand Name E-link Payment Terms T/T,PayPal
Price Negotiated Delivery Time 3-12working days
Minimum Order Quantity 1pcs

Product Description

Mini-type DVI Fiber Optic Extender with external stereo audio

Advantage

· Transmits DVI video signals and audio up to 20km over a single fiber optic cable;

· Compliant with DVI 1.0 specifications ;

· Support 1920*1200 1080P@60Hz

· Special support 1600*1200 @60Hz

· Supporting pixel rates from 25MHz to 165MHz

· DTV resolutions: 480i, 576i, 480p, 576p, 720p, 1080i up to 1080p

Overview

The LNK-MDF100 Series Mini-type DVI Fiber optic extender provides extension of DVI signals long distances

over one fiber optic cable, it supports DVI 1.0 specifications,high resolution up to 1920*1200@60Hz. The

extender can use for a wide range of applications requiring long distance transmission of high resolution with

high quality by its good stability and powerful security.

Mini Industrial PoE Switch Picture

Technical Indexes


Parameter

Description

Video

Standards

DVI1.0 3D; HDCP1.4



Maximum pixel clock

165MHz



Maximum data rate

6.75Gbps



Compliant

1080P@50/59.95/60Hz,( Max 1920*1200@60Hz)

DTV resolutions: 480i, 576i, 480p, 576p, 720p, 1080i,1080p

PC resolutions: VGA, SVGA, XGA, SXGA up to UXGA

Special support 1600*1200 @60HZ



Connector

Female DVI-D



Impedance

100Ω



HDMI Cable Range

<5Meter (Resolution up to 1920*1200@60Hz)

Audio

Interface

3.5MM external stereo audio

Optical fiber

Interface

SFP model – LC connector



Fiber type

Single-mode



Wavelength

850nm/1310nm



Interface bandwidth

3Gbps



Transmission distance

Transmission@1920*1200@60Hz

Multi-mode fiber: <500M

Single-mode fiber: 20km

Other

Power supply

The power adapter: DC 5V



Power dissipation

MAX 1.2W



Temperature

Operating: -20 ~ +70



Humidity

Operating: 5% ~ 90%



Dimension (LxWxH)

80 x 40 x 20 (mm)

Application

Ordering Information

Item

Description

LNK-MDF100

DVI Fiber Optic Extender with external stereo audio:1920*1200P@60Hz, Compliance with DVI 1.0 & HDCP1.2 standard, LC(SFP), Multimode fiber, 300m, including 1 transmitter & 1 receiver, used by pairs

LNK-MDF100S

DVI Fiber Optic Extender with external stereo audio:1920*1200P@60Hz, Compliance with DVI 1.0 & HDCP1.2 standard, LC(SFP), single mode, single fiber, 20km, including 1 transmitter & 1 receiver, used by pairs
