| Price | Negotiation |
| MOQ | 1pcs |
| Delivery Time | 3 working days |
| Brand | E-link |
| Place of Origin | China |
| Certification | CE, ROHS, FCC |
| Model Number | LNK-DAN-D4 |
| Payment Terms | T/T,Western Union,MoneyGram |
| Supply Ability | 5000 Pcs/Month |
| Place of Origin | China | Cable length | 30cm |
| Channels of Audio | 2 Channel Analog | Dimensions | 114 x 30 x 28 mm |
| Model Number | LNK-DAN-D4 | Casing | Plastic casing |
| Supply Ability | 5000 Pcs/Month | Certification | CE, ROHS, FCC |
| Brand Name | E-link | Payment Terms | T/T,Western Union,MoneyGram |
| Price | Negotiation | Delivery Time | 3 working days |
| Minimum Order Quantity | 1pcs | Frequency Response | 20Hz to 20kHz (-/+0.5dB) |
| Net Weight | 145g |
Dante Audio Adapter Technical Indexes
|
Port |
|
|
RJ45 Port |
Network communication port. Green light on indicates system is ready Yellow light flash indicates link/data traffic. When click the "Recognize" button (an eye-shaped symbol) on the Dante controller, Green light will flash to identify the device. |
|
XLR Port |
2 x XLR port, connect output device |
|
Audio |
|
|
Max signal level |
+18 dBu |
|
Output Gain |
-6 dBu |
|
Frequency Response |
20Hz to 20kHz(-/+0.5dB) |
|
Impedance |
150 Ohm balanced, 75 Ohm unbalanced |
|
Dynamic Range |
>100 dB |
|
Signal to Noise Ratio |
>100 dB |
|
THD |
<0.01% @+4dBu |
|
Dante |
|
|
Sample Rate |
44.1kHz, 48kHz, 96kHz |
|
Bit Depth |
24 |
|
Dante Device latency |
1,2 or 5ms (configurable using Dante Controller) |
|
Type |
Analog 0X2 |
|
General |
|
|
Operation Temperature |
-5 to +55℃ (+23° to +131°F) |
|
Storage Temperature |
-25 to +70℃ (-13° to +158°F) |
|
Power |
802.3af PoE |
|
Power Consumption |
2.6W(Max) |
2Ch Analog adapter Ordering Information
|
Model |
Description |
|
LNK-DAN-D4 |
Dante 2Ch Analog Output Dongle Converter |
