| Price | negotiable |
| MOQ | negotiable |
| Delivery Time | within 14 working days |
| Brand | AOJIA |
| Place of Origin | CHINA |
| Certification | ISO90011 |
| Model Number | 114*19.69*15.24 or be customized |
| Packaging Details | Inner packing plastic bag, outer packing superhard carton |
| Payment Terms | L/C, T/T, Western Union |
| Place of Origin | CHINA | coating | TiN, AT, AP, DURANA coating |
| prcoessing method | roughing, semi-finishing, finishing | Packaging Details | Inner packing plastic bag, outer packing superhard carton |
| precision | AAA,AA,DIN3968 | description | high precision Carbide bevel gear cutter tool with coating 114*19.69*15.24 |
| Model Number | 114*19.69*15.24 or be customized | Certification | ISO90011 |
| Brand Name | AOJIA | Payment Terms | L/C, T/T, Western Union |
| material | tungsten carbide, cemented carbide | Price | negotiable |
| Delivery Time | within 14 working days | Minimum Order Quantity | negotiable |
| category | spiral bevel gear cutter | Specificaiton | 114*19.69*15.24 or be customized |
| Application | Gleason bevel gear cutting machine,OERLIKON bevel gear cutting machine |
high precision Carbide bevel gear cutter tool with coating 114*19.69*15.24
Spiral bevel gear cutter tools
coating: TiN, AT, AP, DURANA coating available
Dimension: 114*19.69*15.24
material: original tungsten carbide powder
| Cutter cutting speed table for carbide inserts | ||||||
| serial number | Cutter diameter | cutting speed | Spindle speed | instruction | ||
| 1 | 0.5"/Φ12.7 | 120-180 | 3000-4500 | For 1.1" cutter head, 1.3" cutter head, the cutting speed of 200 m/min can not be achieved, it can be calculated according to the maximum speed of 1890 rpm |
||
| 2 | 1.1"/Φ27.94 | 120-165 | 1360-1890 | |||
| 3 | 1.3"/Φ33.02 | 120-196 | 1150-1890 | |||
| 4 | 1.5"/Φ38.10 | 120-200 | 1000-1670 | |||
| 5 | 2.0"/Φ50.8 | 120-200 | 750-1250 | |||
| 6 | 2.5"/Φ63.5 | 120-200 | 600-1000 | |||
| 7 | 2.75"/Φ69.85 | 120-200 | 550-910 | |||
