| Price | Deliberations |
| MOQ | Deliberations |
| Delivery Time | 5-8 work days |
| Brand | Airui |
| Place of Origin | Shandong，China |
| Certification | ISO/TS16949 |
| Model Number | AC08900301 |
| Packaging Details | 1. Iron frame packing. 2. As your requirements |
| Payment Terms | L/C, T/T |
| Supply Ability | 5000 Piece/Pieces per Month |
| Place of Origin | Shandong，China | Use | Trailer Axle Use |
| Size | 50mm ,free length, Optional | Packaging Details | 1. Iron frame packing. 2. As your requirements |
| length | Customer Model | Material | Steel |
| Model Number | AC08900301 | Supply Ability | 5000 Piece/Pieces per Month |
| Certification | ISO/TS16949 | Surface treatment | Painted Etc |
| Brand Name | Airui | Payment Terms | L/C, T/T |
| spindle lenght | 188.5 mm | Price | Deliberations |
| Delivery Time | 5-8 work days | Minimum Order Quantity | Deliberations |
| Max Payload | 7000 lbs | Brake | Unbrake axle |
What is a drop axle on a trailer?
Drop axles are similar to standard spring axles, but the spindles at the end of the tube bend up. This puts the hub higher up, generally lowering the axle closer to the ground by 4 inches center-to-center. This allows the trailer to sit lower to the ground. Lower deck height means easier loading and unloading.
| 6*5.5", 8*6.5" wheel pattern | |||||
| NO. | Description | QTY | option 1 | option 2 | option 3 |
| 1 | axle shaft | 1 | 50mm Rd / Sq solid | 60mm Rd / Sq solid | 76*6mm round tube |
| 2 | Oil seal | 2 | AC00200400 | AT01700302 | |
| 3 | inner bearing | 2 | 25580/20 | ||
| 4 | ilder hub | 2 | AT01700112 | AT01700112A | |
| 5 | wheel nut | 12,16 | 1/2"-10UNF | ||
| 6 | outer bearing | 2 | 15123/45 | 14125A/76 | |
| 7 | flat washer | 2 | AC00201001 | ||
| 8 | castle nut | 2 | AC00200701 | ||
| 9 | split pin | 2 | AC00200404 | ||
| 10 | dust cap | 2 | AC00200601 | AC00200601B | |
FAQ
Q1,What is your package types?
A:Generally, in neutral white boxes and brown cartons or as ur requirements.
Q2,What is your terms of payment?
A: 30% T/T in advance and 70% before shipping or against by BL copy.
Q3,What is your payment terms?
A: EXW,FOB, CNF & CIF.
Q4,How about your delivery time?
A: Usually,within 30-60 days after receiving the deposit or depending on the order’s requirements.
Q5,Can you produce according to the samples?
A:Yes,we can produce by your samples or technical drawing.
Q6,What is your sample price?
A:Sample design is free, sample and the express cost without free.
Q7,Do you test all your product before delivery?
A:Yes,we have 100% test before delivery.
Q8: How to establish the long-term stable business relationship with your company?
A:We can supply good and competitive price cargo to make sure the win-win relationship.
