| Price | Deliberations |
| MOQ | Deliberations |
| Delivery Time | 5-8 work days |
| Brand | Airui |
| Place of Origin | Shandong，China |
| Certification | ISO/TS16949 |
| Model Number | AC005 |
| Packaging Details | carton, pallet ,plywood case |
| Payment Terms | L/C, T/T |
| Supply Ability | 10000 Piece/Pieces per Month |
| Hub drum body | 5*4.5"/5*4.75"/5*5.0/5*5.5 bolts | Place of Origin | Shandong，China |
| Oil seal | I.D. 43.5 mm single clip | Wheel Nut | 1/2" cone wheel nut |
| Use | Axle Parts | Size | 10 inch |
| bearing | L68149 & L68149 | Packaging Details | carton, pallet ,plywood case |
| Model Number | AC005 | Supply Ability | 10000 Piece/Pieces per Month |
| Certification | ISO/TS16949 | Brand Name | Airui |
| Payment Terms | L/C, T/T | Price | Deliberations |
| Delivery Time | 5-8 work days | Minimum Order Quantity | Deliberations |
| Brake | Hydraulic brake | Dust cap | O.D. 63.7 mm drive in |
| Hub Drum | Bearing | Oil seal | Dust cap | Wheel nut |
| AC00500300A | L68149 & LM12749 | AC00500201 | AC00500405 | AT01600600 |
| Hub drum body cJw 5 * 425" bolts & L68110 /LM12710 bearing race | inner / outer bearing | LD. 43.5rr)m single lip | O.D. 45.4mm drive in | 7/16" cone wheel nut |
| AC00500300F | LM67048& LM11949 | AC00900500 | AC00500405 | AT01600600 |
| Hub drum body cAv 5 * 425" bolts & LM67010 / LM11910 bearing race | inner / outer bearing | LD. 36.5mm single lip | O.D. 45.4mm drive in | 7/16" cone wheel nut |
| AC00500300B | L68149 & LM12749 | AC00500201 | AC00500405 | AC00500302A |
| Hub drum body cA/v 5 * 4.5" bolts & L68110/LM12710bearirQ race | inner / outer bearing | LD. 43.5mm single lip | O.D. 45.4mm drive in | 1/2" cone wheel nut |
| AC00500300G | LM67048& LM11949 | AC00900500 | AC00500405 | AC00500302A |
| Hub drum body cA/v 5 * 4.5" bolts & LM67010 / LM11910 bearing race | inner / outer bearing | LD. 36.5mm single lip | O.D. 45.4mm drive in | 1/2" cone wheel nut |
| AC00500300K | LM67048& LM11949 | AC00900500 | AC00500405 | AT01600600 |
| HUb drum body cAv5 * 120mm bdts & LM67010/LM11910 bearing race | inner / outer bearing | LD. 36.5mm single lip | O.D. 45.4mm drive in | 7/16" cone wheel nut |
| AC00500300LB | L68149 & LM12749 | AC00500201 | AC00500405 | AC00500302A |
| HUb drum body dw5 * 120mm bolts &L68110/LM12710 bearing race | inner / outer bearing | LD. 43.5rr)m single lip | O.D. 45.4mm drive in | 1/2" cone wheel nut |
| AC00500300C | L68149 & LM12749 | AC00500201 | AC00500405 | AT01600600 |
| Hub drum body cAv 5 * 4.75" bolts & L68110/LM12710bearirQ race | inner / outer bearing | LD. 43.5mm single lip | O.D. 45.4mm drive in | 7/16" cone wheel nut |
| AC00500300H | LM67048& LM11949 | AC00900500 | AC00500405 | AT01600600 |
| Hub drum body cAv5* 475" bolts & LM67010 / LM11910 bearing race | inner / outer bearing | LD. 36.5mm single lip | O.D. 45.4mm drive in | 7/16" cone wheel nut |
| AC005003000 | L68149 & LM12749 | AC00500201 | AC00500405 | AT01700134C |
| Hub drum body cAa/5* 150mm bolts &L68110/LM12710 bearing race | inner / outer bearing | LD. 43.5mm single lip | O.D. 45.4mm drive in | 9/16" cone wheel nut |
| AC00500300D | L68149 & LM12749 | AC00500201 | AC00500405 | AC00500302A |
| Hub drum body cAv 6 * 5.5" boHs & L68110/LM12710 bearing race | inner / outer bearing | LD. 43.5rr)m single lip | O.D. 45.4mm drive in | 1/2" cone wheel nut |
| AC00500300I | LM67048& LM11949 | AC00900500 | AC00500405 | AC00500302A |
| Hub drum body c/v 6 * 5.5" bolts & LM67010 / LM11910 bearing race | inner / outer bearing | LD. 36.5mm single lip | O.D. 45.4mm drive in | 1/2" cone wheel nut |
| AC00500300DA | L68149 & LM12749 | AC00500201 | AC00500405 | AC00500302A |
| Hub drum body c/a/6* 140mm bolts &L68110/LM12710 bearing race | inner / outer bearing | LD. 43.5rr)m single lip | O.D. 45.4mm drive in | 1/2" cone wheel nut |
1: Could you please make us an offer as soon as possible?
In order to get the price quickly and accurately, please provide the technical drawing or OE number, we will be very grateful.
2: Could you please provide us with the specifications of the products?
Sure, please confirm the product code you need before that.
3: How can you guarantee the quality of your products?
Our products have passed ISO9001 international quality standard certification. Our company has a very strict quality control system.
Features:
Single-piece assembly makes installation a snap, whether you're retrofitting or switching from drum brakes
Machined process minimizes runout and warping
Contaminants can't get in between rotor and hub
Balanced unit provides smooth ride
Vented design effectively dissipates heat, preventing heat-related damage
1/2" Wheel studs and industry-standard races are included
Cast iron construction ensures a favorable friction coefficient for necessary stopping power
Description
1. Forged hub,(material C45) + square spindle (material St52-3) + yellow zinc bolts and nuts
2. Max. speed: 40km/h
3. Black color like in the picture with unti-rust oil; color painting as customers' requirements; zinc plating as requirement.2.Track:accept customized.
4.Axle Beam:Round,Square for optional.
5. Full axles & stub axles for agricultural equipment
6.Track length can be met according to customers'request.
As for the transportation of products, our company supports various sea, land and air international transportation. Please confirm the specific transportation plan during the negotiation.
