| Price | Negotiation |
| MOQ | Negotiation |
| Delivery Time | 5-8 working days |
| Brand | BAIDUN |
| Place of Origin | China |
| Certification | CE、FC、ROHS |
| Model Number | 3.2V230AH |
| Packaging Details | The box size is 370*260*240mm, Use high-density foam to fix, one box contains two batteries |
| Payment Terms | Credit card, T/T,PayPal |
| Supply Ability | ≥30000 pieces/month |
| Place of Origin | China | Warranty | 3 Years |
| Cycle life | 3500 cycles | Size | 174*54*205mm |
| Packaging Details | The box size is 370*260*240mm, Use high-density foam to fix, one box contains two batteries | Color | Blue |
| Battery Size | 3.2V230AH | Model Number | 3.2V230AH |
| Supply Ability | ≥30000 pieces/month | Terminal | Welding studs |
| Certification | CE、FC、ROHS | Weight | 4.2KG |
| Brand Name | BAIDUN | Payment Terms | Credit card, T/T,PayPal |
| Screw Hole | M6 | Price | Negotiation |
| Delivery Time | 5-8 working days | Minimum Order Quantity | Negotiation |
| Application | Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Su | Internal Resistance | ≤0.25mΩ |
This product is a 3500 cycle 3.2 v230ah lithium iron phosphate rechargeable battery, a genuine well-known brand battery, with original QR code, A grade, oval terminals, which can be punched screw holes or welded studs. With a square aluminum shell structure, safe explosion-proof, no leakage, high discharge rate, low resistance, high capacity, long cycle life, green and environmental protection, it can be used for various electric vehicles, household energy storage, communication energy storage and solar energy storage. network requirements. It has a wide range of applications, is easy to assemble, and can be made into 12V24V48V or even larger battery packs in series or parallel
| Item | Parameter | Remark | |
| Nominal Capacity | 230.0Ah | 1C , 25°C±2°C , 2.5-3.65V | |
| Minimum energy | 736.0Wh | 1C , 25°C±2°C , 2.5-3.65V | |
| Initial internal resistance | ≤0.5mΩ | AC , 1kHz , 30%〜40%SOC | |
| standard | 3.2V | 0.5C , 25°C±2°C , 2.5-3.65V | |
| Battery weight | 4140±124g(±3%) | ||
| Charging limit voltage(Umax) | 3.65V | ||
| Discharge cut-off voltage(Umin) |
2.5V (T >0°C) 2.0V (T <0°C) |
||
| Charge | Standard charging current | 115.0A | 0.5C |
| Discharge | Standard discharge current | 230.0A | 1C |
| Cycle performance | 25°C standard cycle | 3500 cycles@0.5C/1C | Under the 300kgf clamp, after standard charged and 30mins rest, discharge to 2.5V cutoff with the current of 0.5C(A) at (25±2) °C/(45±2) °C, and then start the next cycle, end with the capacity decreasing to 80% of the initial capacity. The number of cycles is defined as the cycle life of the battery. |
| 45°C standard cycle | 1800 cycles@0.5C/1C | ||
| Operating temperature | Charging temperature | 0 〜60°C | |
| Discharge temperature | -30〜60°C | ||
| storage temperature | 3 months | 0 〜45°C | |
| 1 months | -20~45°C | ||
|
Aluminum bar welding parameter |
Laser welding penetration | ≤ 2.0mm | |
| The maximum pressure of the pole | 700N | The pole can bear the maximum vertical force without deformation | |
| The pole can bear the maximum torque | 6N.m | The pole is subjected to maximum distortion without loosening | |
| The pole can withstand the maximum temperature | 130°C | The pole can withstand the maximum temperature, and the plastic pad will not be deformed | |
|
No. |
Item | Parameter | Parameter | |
| 1 | Dimension | High (total) | 207.2±0.5mm | |
| High (subject) | 204.6±0.5mm | |||
| Width | 173.93±0.5mm | |||
| Average thickness | 53.85±0.4mm (under 300kgf , 30%SOC 〜40%SOC) | |||
| 2 | Battery weight | Weight (including blue film, top patch) | 4140±124g(±3%) | |
Product Description:
1. We order batteries directly from the brand. Guarantee A grade, brand new, genuine, sufficient capacity, voltage, resistance, and data matching.
2. There are three styles of battery square terminals to choose from. They are: original terminals, punched terminals and soldered studs. Punch M6, stud M6. Generally, welding studs are easier to assemble.
3. A battery is equipped with a bus bar and two screws as standard. [Bus size: 78*54*2mm (copper nickel plating) screw size: M6]
4. Lithium battery modules are connected in parallel or in series
5. Warranty period: 3 years
Application areas:
1. RV, caravan, electric bicycle/motorcycle/scooter, golf cart/baby stroller, electric scooter
2. Solar energy system, wind energy system, household energy storage system, backup system and UPS
3. Modal equipment, consumer electronics, power tools and engine starting batteries,
4. Flashlights, LED emergency lights, solar street lights, decorative lighting, yachts, lawn mowers, etc.
WFeatures of lifepo4 lithium battery:
1. Long life span, 4 times that of ordinary lead-acid batteries. If you want to upgrade from a lead-acid battery to a lithium battery, this is a good choice.
2. Safe to use. The lithium iron phosphate battery has undergone strict safety tests and will not explode even in a serious collision.
3. Large capacity, high temperature resistance, good performance, small size, light weight, environmentally friendly materials.
