| Price | Negotiable |
| MOQ | 1 |
| Delivery Time | 30-45 work days |
| Brand | Remarkable |
| Place of Origin | Henan, China |
| Certification | CE, ISO |
| Model Number | KPD |
| Packaging Details | 1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes. |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 600 |
| Load | 30 tons | Place of Origin | Henan, China |
| Traveling speed（m/min） | 0-20 (Stepless speed regulation) | Packaging Details | 1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes. |
| table size | customized | Power supply | low voltage rail power |
| Model Number | KPD | Supply Ability | 600 |
| Certification | CE, ISO | Other function | Equip with turning light, night light, battery display, etc. |
| Brand Name | Remarkable | Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Ground type | track | other name | coil material transport car |
| Price | Negotiable | Delivery Time | 30-45 work days |
| Minimum Order Quantity | 1 | Operation method | Wireless remote control & Hand operate pendant |
Remote Control Material Handling Cart , 30T Heavy Duty Transport Trolley
Main working mode of low-voltage track flat car: reduce the voltage of 380V power supply (three-phase or single-phase) to 36V safety voltage through transformer. By transferring the wheel sliding block, 36V is sent to the step-up transformer in the vehicle and installed in the electrical box. The transformer converts 36V to 380V. Then, the AC control system provides 380V power for the electric flat car to start, stop, and move forward or backward. The low-voltage rail flat car can be installed on the S-shaped curved rail. It can also be equipped with hydraulic lifting system and lifting system. All accessible places shall be insulated to prevent electric leakage. Kpdz series rail flat car box girder structure has compact structure, convenient use and strong bearing capacity. It can be started and stopped frequently. DC motor is selected to start stably and have large starting torque.
Remote Control Material Handling Cart , 30T Heavy Duty Transport Trolley
Henan Remarkable Intelligent Technology Co., Ltd is a professional handling equipment company integrated intelligent R&D, design, manufacturing, sales as well as after-sales service. It specializes in producing electric transfer carts of various tonnages, handling equipment accessories, intelligent crane and crane accessories with professional design, development and manufacture of non-standard, intelligent electric transfer carts and handling robots. According to different power mode, the handling equipment products can be divided into six series including low-voltage track-powered, battery-powered, towline-powered, cable reel-powered, safe-trolley-line powered, and unpowered traction.
| Technical parameters for Low-voltage track powered electric transfer carts KPD series | ||||||||||
| Model | KPD-6t | KPD-10t | KPD-16t | KPD-25t | KPD-40t | KPD-63t | KPD-100t | KPD-160t | KPD-200t | |
| Rated load (t) | 6 | 10 | 16 | 25 | 40 | 63 | 100 | 160 | 200 | |
| Countertop size (mm) |
Length | 3600 | 3600 | 4000 | 4500 | 5000 | 5600 | 6300 | 8000 | 8200 |
| Width | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2800 | 2800 | 3000 | |
| Height | 550 | 550 | 600 | 650 | 700 | 850 | 900 | 1100 | 1250 | |
| Speed(m/min) | 30 | 30 | 30 | 30 | 25 | 25 | 20 | 20 | 18 | |
| Wheel base A(mm) | 2000 | 2200 | 2200 | 2500 | 2800 | 3200 | 3600 | 5000 | 5000 | |
| Track medial distance C(mm) | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1650 | 2000 | 2000 | |
| Wheel diameter(mm) | 400 | 400 | 400 | 500 | 500 | 600 | 700 | 700 | 700 | |
| Bottom clearance(mm) | 50 | 50 | 50 | 60 | 60 | 60 | 60 | 70 | 70 | |
| Minimum turning radius | 30 | 35 | 50 | 55 | 60 | 80 | 100 | 100 | ||
| Motor model / power (Kw) |
KPD (single-phase) |
JDYP-11-6 | JDYP-12-6 | JDYP-21-6 | JDYP-22-6 | |||||
| 2.2 | 3.5 | 5 | 7.5 | |||||||
|
KPD (three-phase) |
YZ132M1-6 | YZ132M2-6 | YZ160M1 -6 |
YZ160M2-6 | YZ160L-6 | YZ160M2 -6 |
YZ160L -6 |
|||
| 2.2 | 3.7 | 5.5 | 7.5 | 11 | 2×7.5 | 2×11 | ||||
| Power mode | KPD | 380V reduced to 36V / 360V reduced to 36V then boosted to 380V | ||||||||
| Recommended track model | 24kg/m | 38kg/m | 43kg/m | QU80 | QU100 | |||||
| Number of wheels | 4 | 8 | ||||||||
| Maximum wheel Pressure (t) | 1.91 | 3.21 | 4.87 | 7.5 | 11.5 | 16.9 | 27.6 | 22.8 | 28.5 | |
| Reference weight (t) | 3.4 | 3.72 | 4.2 | 6 | 8.5 | 11.4 | 15.2 | 25.5 | 31.5 | |
