15KW Water Cooling Vacuum Brazing Machine For PCD PCBN Tools

Price	Negotiable
MOQ	1 SETS
Delivery Time	5-60 WORKING DAYS
Brand	CHN-TOP
Place of Origin	CHINA
Certification	CE
Model Number	ZT-ZKHJ180/E
Packaging Details	WOODEN CASE
Payment Terms	L/C, T/T, D/A, MoneyGram
Supply Ability	50 SETS/MONTH

Product Details

Product Specification

Place of Origin	CHINA	Packaging Details	WOODEN CASE
Model Number	ZT-ZKHJ180/E	Supply Ability	50 SETS/MONTH
Certification	CE	Brand Name	CHN-TOP
Payment Terms	L/C, T/T, D/A, MoneyGram	Brand	CHN-TOP
Model No.	ZT-ZKHJ180/E	Price	Negotiable
Delivery Time	5-60 WORKING DAYS	Minimum Order Quantity	1 SETS
Chamber Size	180*500mm	Height	500mm

Product Description

BRAZING MACHINE FOR TOOLS MACHINING PCD BLANK BRAZING MACHINE PCD TOOLS EQUIPMENT TOOL INSERT BRAZING NO OXIDATION

ZT-ZKHJ180E is a economic model for PCD PCBN diamond tools

No oxidation
Easy temperature control
Work environment improvement
Total cost efficiency
Enhancement of strength
Reduction of distortion

MAIN FEATURES

1, PLC control, SCR heating, touch panel,

automatic implement after simple setting with easy temperature control.

2, No oxidation, clean surface, environment-friendly.

3, Brazing quantity is more than 500pcs (for CNGA1204), reduce total cost.

4, The machine is fully automatic and once loaded, the cycle time is approximately 70-120 mins.

5, Reduction of distortion even very small tool insert can be brazed.

6, High brazing strength, 2 times higher than induction welding.

7, Advanced artificial quartz stone for table-board, elegant, high temperature resistance.

Besides the standard machine, we can offer OEM according to clients’ requirement.

Technical Parameters:


			Dimensions

			1020*680*1130mm(L*W*H)

			Power

			3 Phase 5 wires

			Chamber material

			Quartz Glass Tube

			Chamber size

			180E: ∮180*500*T4

			Max temparature

			950℃

			Max Vacuum Rate

			10ˉ6 Torr(10ˉ4 Pa)

			Vacuum Rate

			10ˉ4 Torr(10ˉ2 Pa)

			Heating Source

			18 pcs halogen tubes

			Chilling

			Water cooling

			Vacuum Process

			Clean, fitting paste,drying, and brazing

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufactory for PCD,CBN diamond tools equipments and service, we have our own R&D
team and production workshop. We can develop our customers' unique products according to their needs.

Q: How long is your delivery time?

A: Generally it is 2-3 days for CNC diamonds tools machining, and 45-60 days for machines.

Q: How about your after-sales system?

A: We have a comprehensive after-sales system, which can provide one-on-one online video service
according to the needs of customers, and one-on-one service to solve customers' worries.

Q: How about your delivery date for PCD/PCBN blank?

A: 1), PCD/PCBN Blank, we have signed a Chinese agency agreement with international big brands,
customers do not need to worry about genuine and delivery problems;

2), We can provide a wide range of products with PCD/ PCBN Blank, customers can choose goods according
to different needs, we also have self-developed domestic PCD with high quality, the price is very competitive.

Q: How about the cutting thickness and width of Laser cutting machine?

A: 1), Cutting thickness, single-sided cutting maximum thickness of 4-5mm, double-sided cutting maximum
thickness of 8 10mm.

2), Slit width: 0.05-0.15mm, accuracy can reach 0.01mm.
