| Price | RMB＞100000UNIT |
| MOQ | 1 |
| Delivery Time | 10DAYS |
| Brand | Hydeb |
| Place of Origin | CHINA |
| Certification | ISO |
| Model Number | HDR-2000 |
| Packaging Details | WOODEN PACKAGE |
| Payment Terms | T/T, Western Union, MoneyGram |
| Supply Ability | 500SETS/YEAR |
| Launder Lining Life | ≥12 Months | Rotor Swing Range | 30° |
| Packaging Details | WOODEN PACKAGE | Supply Ability | 500SETS/YEAR |
| Colour | Green | Minimum Order Quantity | 1 |
| Shaft Material | Graphite | Number Of Heaters | 2 |
| Insulation | Ceramic Fiber Blanket | Place of Origin | CHINA |
| Color | Blue Or Customized | Max Flow Rate | 15 Liters Per Minute |
| Model Number | HDR-2000 | Certification | ISO |
| Degassing Efficiency | 60% | Brand Name | Hydeb |
| Payment Terms | T/T, Western Union, MoneyGram | Input Frequency | 50/60Hz |
| Price | RMB＞100000UNIT | Delivery Time | 10DAYS |
| Gas | High Purity Nitrogen | Fluxing Granularity | ≤5 Mm |
| Warranty Time | 1 Year | Power Consumption | 2.5KW |
| Power | 380/50Hz/3Phases |
2. EQUIPMENT CONFIGURATION
| Name | Qty | Remark | |
|
Host part |
Mobile box walking mechanism | 1 set | |
| Tilting system | 1 set | ||
| Rotor rotation system | 1 set | ||
| Rotating Mechanism Swing System | 1 set | ||
| Fluxing spraying system | 1 set | ||
| Frame | 1 set | ||
| Control system | Nitrogen / argon gas system | 1 set | |
| Electric control system | 1 set | ||
| Control cabinet | 1 pc | ||
|
Others |
Graphite rotor | 1 set | |
| Graphite shaft | 1 set | ||
| Main shaft insulation board | 1 set | ||
3. MAIN PARAMETERS
| Item | Data | Remark | ||
| Refined gas | purity % | ≥99.996 |
High purity nitrogen or argon
|
|
| water content ppm | ≤ 3 | |||
| O2 ppm | ≤ 5 | |||
| Pressure MPa | 0.1-0.6 adjustable | |||
| Flow rate L/min | 15～30 adjustable | |||
| Compressed air | Pressure MPa | ≥0.4 | ||
| Flow rate m3/h | ≥0.5 | |||
| Power parameters | Power phase number | 3 | ||
| voltage V | 380 | |||
| Frequency Hz | 50 | |||
| Gross power kW | 15 | |||
| Mobile box mobile motor | Power kW | 0.75 | Used for mobile box walking | |
| Rotating shaft motor | Power kW | 11 | Used to drive rotation of graphite shaft | |
| Rotating motor of rotating mechanism | Power kW | 0.2 | Used to drive the fuselage rotation | |
| Motor of powder feeding device | Power kW | 0.2 | Used to drive the powder feeding device | |
| Tilting system | Power kW | 1.5 | Used for mainshaft turnover | |
| Rotor swing range | ||||
| Rotor tilting range mm | See scheme drawing of rotary Fluxing Injector | |||
| Rotation speed of graphite rotor r/min | 100－400 | Frequency conversion adjustment | ||
| Refining degassing time min | 0～99 | Time-adjustable | ||
| Temperature of molten aluminum ℃ | 640-850 | Temperature of Refined molten aluminum | ||
| Graphite rotor size | Diameter x length mm | Details seeing drawing | ||
| Graphite rotor size | Diameter x length mm | Details seeing drawing | ||
| Overall size | Length x width x height mm | Details seeing drawing | ||
| Weight kg | About 3000 | Subject to actual production | ||
SUPPORT
AND
SERVICE
The
In-Furnace
Rotor
Refining
Equipment
is
supported
by
a
complete
set
of
technical
services
to
ensure
stable
operation
and
high
customer
satisfaction.
Our
experienced
technical
team
provides
guidance
for
installation,
debugging,
and
regular
maintenance.
We
also
offer
training
programs
to
help
users
understand
optimal
refining
practices,
enhance
process
control,
and
fully
utilize
the
equipment's
capabilities.
Our
service
team
is
committed
to
delivering
prompt
and
effective
solutions,
ensuring
your
equipment
operates
reliably
and
efficiently
in
demanding
production
environments.
PACKING AND SHIPPING:
Product
Name:
In-Furnace
Rotor
Refining
Equipment
Description:
High-efficiency
in-furnace
rotor
system
designed
for
uniform
flux
dispersion
and
enhanced
aluminum
melt
purification.
Features:
Corrosion-resistant
graphite
rotor
and
shaft
Uniform
and
controlled
refining
process
PLC-controlled
operation
for
precision
Suitable
for
continuous
or
batch
aluminum
processing
Packaging:
The
In-Furnace
Rotor
Refining
Equipment
is
securely
packed
in
a
reinforced
wooden
crate
with
shock-absorbing
foam
to
prevent
damage
during
transit.
Shipping:
We
provide
global
shipping
for
the
In-Furnace
Rotor
Refining
Equipment.
Shipping
costs
vary
by
destination
and
selected
delivery
method.
Please
allow
2–3
business
days
for
processing
before
shipment.
FAQ:
Q:
What
is
the
brand
name
of
the
In-Furnace
Rotor
Refining
Equipment?
A:
The
brand
name
is
HYDEB.
Q:
Where
is
the
In-Furnace
Rotor
Refining
Equipment
manufactured?
A:
It
is
manufactured
in
Shandong,
China.
Q:
What
certifications
does
the
product
have?
A:
The
equipment
is
certified
with
CE
and
ISO
standards.
Q:
What
is
the
minimum
order
quantity
for
this
product?
A:
The
minimum
order
quantity
is
1
SET.
Q:
What
are
the
accepted
payment
terms?
A:
Payment
is
accepted
via
T/T
(Telegraphic
Transfer),
with
a
30%
deposit
and
70%
before
delivery.
