| Price | Negotiable |
| MOQ | 1 |
| Delivery Time | Negotiable |
| Brand | DURA |
| Place of Origin | Jiangsu, China |
| Servo motor power | 1KW | Phase | 3-phase |
| Place of Origin | Jiangsu, China | Core components | PLC, Motor |
| Main motor power | 1.5KW | Weight | 720 kg |
| Wire payoff inverter | 1.5KW | Process Length | 13", 14", 15", 16", 18" |
| Brand Name | DURA | Wire diameter range | 1.8~2.8mm |
| Main machine inverter | 2.2KW | Capacity | 27-30pcs/min |
| Minimum Order Quantity | 1 | Voltage | 380V |
| Frequency | 50Hz | Material type | Galvanised steel wire or bright steel wire |
| Wire payoff dimensions | 100*1200*900mm | Main machine dimensions | 1950*800*1550mm |
| Model | QK-3 QK-3-A: with normal wire payoff QK-3-B: with motor-driven wire payoff |
| Process Length Rating | 13", 14", 15", 16", 18" |
| Capacity | 27-30 pcs/min |
| PLC & Touch Screen | Set and display all required data including hanger length, capacity, feed/return, self-stop and count functions |
| Materials | Galvanised steel wire or bright steel wire Wire diameter range: 1.8~2.8mm |
| Main Motor | 1.5KW (380V, 50Hz, 3-phase) |
| Servo Motor Power | 1KW |
| Frequency Inverters | 2.2KW for main machine 1.5KW for motor-driven wire payoff |
| Overall Dimensions | Main machine: 1950×800×1550mm Motorized wire payoff: 100×1200×900mm |
