| Price | Negotiable |
| MOQ | 3pcs |
| Delivery Time | 5-7days |
| Brand | Anping XinLu Wire Mesh Products Co.,Ltd |
| Place of Origin | Anping County, Hebei Province, China |
| Certification | ISO |
| Model Number | XL - V Wire Screen Pipe - 010 |
| Packaging Details | wooden, pallet |
| Payment Terms | T/T, L/C |
| Supply Ability | 100pcs / 15days |
| Another name | Water Well Screen, V Wire Screen, Johnson Screen Tube, Sand Control Filter Screen | Usage | water well, oil well drilling, water treatment, filter, mineral, gas /oil filtration, Industry, food,etc |
| Place of Origin | Anping County, Hebei Province, China | V / Wedge Wire | #63, #93, #118, #121,#130 |
| Packaging Details | wooden, pallet | Hole shape | Wedge,v-shape |
| DN | 168.3mm (6-5/8") | Material | stainless steel 304, or 205, 304L, 316L ,321, Duplex stainless steel, etc. |
| Model Number | XL - V Wire Screen Pipe - 010 | Supply Ability | 100pcs / 15days |
| Feature | Non-magnetic,Corrosion Resistance, Non-clogging,Easy Installation | Certification | ISO |
| Brand Name | Anping XinLu Wire Mesh Products Co.,Ltd | Payment Terms | T/T, L/C |
| Price | Negotiable | Delivery Time | 5-7days |
| Weave style | Wedge Wire Wrapped | Minimum Order Quantity | 3pcs |
Water Well Sand Control Filter 168mm Johnson Stainless Steel V Wire Screen Tube
stainless steel vee sharped wire / wrap wire, johnson screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainess steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod basedc ontinuous slot screens, header and hub laterals & hub radial laterals etc.
The water well sand control filter screen tube is composed of a "V"-shaped or wedge-shaped stainless steel wire and a stainless steel support bar. The smooth surface of the filter element is the filter surface, and the gaps are strips, which belong to the surface filter form. As a variety of automatic filters (such as automatic backwashing, scraper self-cleaning, scraper self-cleaning, suction self-cleaning filter) filter elements are widely used in fluid filtration in various industries.
|
Sizes (inch) |
OD (mm) |
Slot (mm) |
Length (m) |
Tenslie Strength |
Collapse Strength |
Wrap wire Vee-shaped wire(mm) |
Support rod Round wire(mm) |
| 3-1/2 | 88.9 | 1.0 | 2.9 | ＞22 | 10.2 | 2.2*3.5 (Width*height) | ø3.8MM×22 |
| 4-1/2 | 114.3 | 1.0 | 2.9 | ＞28 | 11.5 | 2.2*3.5(Width*height) | ø3.8MM×22 |
| 6-5/8 | 168.3 | 0.75 | 5.8 | ＞40 | 12.8 | 2.2*3.5(Width*height) | ø3.8MM×32 |
| 6-5/8 | 168.3 | 1.0 | 5.8 | ＞33 | 12.8 | 2.2*3.5(Width*height) | ø3.8MM×32 |
| 6-5/8 | 168.3 | 0.63 | 5.8 | ＞83 | 45 | 3.2*6.0(Width*height) | ø6.0MM×32 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞34 | 21.9 | 2.3*3.5(Width*height) | ø3.8MM×48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞50 | 38.2 | 3.0*5.0(Width*height) | ø4.0MM×48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞60 | 46 | 3.2*6.0(Width*height) | ø5.0MM×48 |
| 10-3/4 | 273.1 | 0.75 | 5.8 | ＞50 | 32.9 | 2.2*3.5(Width*height) | ø4.0MM×55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞60 | 39.5 | 3.0*4.6(Width*height) | ø4.8MM×55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞100 | 48 | 3.2*6.0(Width*height) | ø5.0MM×55 |
| 12-3/4 | 323.9 | 1.0 | 5.8 | ＞120 | 37.2 | 3.0*5.0(Width*height) | ø4.0MM×56 |
| 14 | 355.6 | 1.0 | 2.9 | ＞80 | 37.8 | 3.0*5.0(Width*height) | ø4.0MM×59 |
| 16 | 426 | 1.0 | 2.9 | ＞80 | 37.5 | 3.0*5.0(Width*height) | ø4.0MM×54 |
Advantages of V Wire Screen Tube Pipe:
Non-clogging capabilities
Self supporting
High abreaction resistance
Large open area
Better sand filtration
Energy saving
Lowest possible cost
Long using life
Maximum flow capacity
Use:
water well
Juice
Beer
water
supply
systems
Refining
&
petrochemical
Filter
equipment
Drum
Filter
Sand
control
Groundwater
Pump Filter
Motor Filter
Dewatering
Pharmaceutical
Waste water treatment
We
can
produce
products
according
to
the
needs
of
our
customers.
Material:
stainless
steel
304,
316L,
low
carbon
steel
Diameter:
minimum
diameter
32mm,
maximum
diameter
1270mm
Length:
single
tube
can
be
up
to
6
meters
in
length
Gap:
0.25mm,
0.5mm,
0.7mm,
1.0mm,
1.5mm
is
a
regular
gap.
We
can
produce
gaps
of
0.1-50mm
Joints:
Generally,
there
are
joints
at
both
ends
of
the
pipe,
such
as
flanges,
weld
rings,
or
threads,
so
that
the
pipes
can
be
connected
to
meet
---------------------------------------------------------------------------------------------------------------
Anping XinLu wire mesh products co.,ltd, it is a manufacturer and exporter of wedge wire screen products.
-----------------------------------------------------------------------------------------------------------------------------------------------
FAQ
Q0. What's the well deep can it used?
A: The common is used in the deep of 200-300m.
Water well screen pipes with the largest wire can be used for a depth of 650m.
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing , 15-25 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 3pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline, sea shipping and rail transportation are all optional.
Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.
Q5. How to proceed an order?
A: Firstly let us know your need specification or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
Johnson
V
Wire
Screen
Tube,
Wedge
Wire
Oil
Filter
Tube
Production
Process
and Pictures:
