| Price | 1-30 Square Meter $2/Square Meter >30 Square Meters $1/Square Meter |
| MOQ | 1 Square Meter |
| Delivery Time | 5-8 work days |
| Brand | FUHANG |
| Place of Origin | China |
| Certification | ISO9001 |
| Model Number | 40x200 Mesh |
| Payment Terms | L/C, T/T |
| Supply Ability | 50000 square meter /15 Days |
| Usage | filter | Place of Origin | China |
| Sample | free | Color | Silver |
| Material | Stainless Steel Wire,304,316 | Model Number | 40x200 Mesh |
| Supply Ability | 50000 square meter /15 Days | Feature | Acid-resisting,Anti-corrosion,alkali-resisting etc |
| Certification | ISO9001 | Brand Name | FUHANG |
| Payment Terms | L/C, T/T | Type | Weave Wire Mesh |
| Advantage | factory direct sale | Packing | paper tube inside+ wodden box +plastic bag + |
| Price | 1-30 Square Meter $2/Square Meter >30 Square Meters $1/Square Meter | Delivery Time | 5-8 work days |
| Product name | 40x200 Mesh Dutch Weave Micronic Filter Cloth | Weave style | Dutch/Plain/Twill Weave |
| Length | 1-30m | Minimum Order Quantity | 1 Square Meter |
| Technique | Woven | Application | Woven Wire Mesh |
| Width | Usually1M |
T304/T316 40x200 Mesh Dutch Weave 55 Micron Filter Cloth
Mesh with a Dutch weave is woven to a precise tolerance for a much denser finished material with small, curved tunnel-shaped openings. Light does not pass through Dutch-woven micronic filter mesh. Thick and sturdy Dutch weaves are typically used for hydraulic fluid filters, gas diffusers, vacuum filters, pressure liquid filters, and breather vents.
Dutch weave is divided into plain Dutch weave and twill Dutch weave. 40x200 Mesh uses plain Dutch weave.
| U.S. | Metric | |
| MESH SIZE | 40x200 per in | 40x200 per 2.54 cm |
| WIRE DIAMETER | 0.0070x0.0055 in | 0.1778x0.1397 mm |
| OPENING | 0.0022 in | 0.05588 mm |
| OPENING MICRONS | 55 | 55 |
| POROSITY | 63 | 63 |
| OVERALL THICKNESS | 0.0180 in | 0.4572 mm |
| WEIGHT/SQUARE FOOT | 0.2800 lb | 0.1271 kg |
Features
55 micron precision woven stainless steel screen
Used in separation, fuel filters, gas diffusers and vents
Light tight mesh
Flow Data is available
Meets ASTM E2814-18
Stainless Steel 304/316
Applications
of
dutch
weave
woven
wire
mesh
1.
Dutch
weave
woven
wire
mesh
is
mainly
used
for
filtering.
It
provides
superior
filtration
capabilities
for
a
wide
range
of
areas
applications.
Aerospace.
Petrochemical.
Pharmaceutical.
Mining.
Waste
water.
2.
According
to
the
material
of
filtering,
the
plain
dutch
and
twill
dutch
can
be
used
in
different
applications.
The
plain
dutch
weave
woven
wire
mesh
is
mainly
used
for
filtering
and
separating
liquid
and
slurry
products.
The
twill
dutch
weave
woven
wire
mesh
is
used
for
filtering
heavy
materials.
