| Price | USD $0.5~$0.65 per piece |
| MOQ | 200 |
| Delivery Time | 10 work days |
| Place of Origin | China |
| Model Number | ANS-B |
| Packaging Details | 100pcs per bag, 5000pcs per box |
| Payment Terms | T/T |
| Supply Ability | 5K pieces per week |
| Total Length | 42mm | Place of Origin | China |
| Halogen free | Yes | Shell material | PC |
| Voltage Rating | 32V dc | Packaging Details | 100pcs per bag, 5000pcs per box |
| Operation temp | -40˚C to +125˚C | Standard | ISO8820-5 |
| Model Number | ANS-B | Mounting Type | Bolt down |
| Supply Ability | 5K pieces per week | Terminal material | nickel plated zinc alloy |
| MPQ | 100pcs per bag | Payment Terms | T/T |
| Item Name | Bolt Down Fuse | Current Ratin0.1A~20Ag | 30A 40A 50A 60A 70A 80A 100A 125A 150A 200A |
| Price | USD $0.5~$0.65 per piece | Delivery Time | 10 work days |
| Part No. | ANS-B | Minimum Order Quantity | 200 |
| Hole Distance | 30mm | Hole Diameter | 5.5mm |
| RoHS Compliant | Yes | Interrupting Rating | 2000A @ 32 VDC |
Mini Bolt On Automotive Limiter Fuse Strip MIDI Fuse ANS-B Fuse 30A 40A 50A 60A 70A 80A 100A 125A 150A 175A 200A
Product Description
| Product Name | Mini Bolt-on Fuse ANS-B |
| Types | Bolt-down |
| Volt Rating | 32V dc |
| Amp Rating | 30A 40A 50A 60A 70A 80A 100A 125A 150A 200A |
| Blow Types | standard |
| Environmental | Lead and Ph free |
| Package | 100pcs per bag |
| Specification | Parameters |
| Interrupting Rating: | 2000A @ 32 VDC |
| Voltage Rating: | 32 VDC |
| Temperature Range: | -40°C to +105°C |
| Terminals: | nickel plated zinc alloy |
| Housing Material: | PC |
| Complies with: | IS08820-5 |
Blowing Performance
| TESTING CURRENT | BLOW TIME LIMIT |
| 100% | 100 Hr. minimum |
| 150% | 90s--- 3600s |
| 200%(≥150A) | 3s --- 100s |
| 300% | 0.3s-3s |
| 350%(≥150A) | 0.3s-5s |
Drawing of ANS-B fuses
Ratings & Colors
| P/N | Amps | Color |
| ANS-B-30 | 30A | orange |
| ANS-B-40 | 40A | green |
| ANS-B-50 | 50A | red |
| ANS-B-60 | 60A | yellow |
| ANS-B-70 | 70A | brown |
| ANS-B-80 | 80A | transparent |
| ANS-B-100 | 100A | blue |
| ANS-B-125 | 125A | pink |
| ANS-B-150 | 150A | grey |
| ANS-B-175 | 175A | / |
| ANS-B-200 | 200A | / |
Standard Package
100pcs per bag, 5000pcs per carton
Shipping Term:
EXW, DDU, DDP, C&F, FOB
Shipping Methods:
International Express, By Air, By Sea
