| Price | negotiable |
| MOQ | 100pcs |
| Delivery Time | 15-25days |
| Brand | HBGB |
| Place of Origin | China |
| Certification | ISO9001 |
| Model Number | GB-007 |
| Packaging Details | bulk packing, in bundle or by pallet |
| Payment Terms | L/C, T/T |
| Supply Ability | 3000 pcs per day |
| Place of Origin | China | Bearing Bar | 30mm high x 3mm thickness or 32mm high x 5mm thickness |
| Bearing bar pitch | 30mm,40mm,60mm | Bearing bar type | Flat bar,serrated bar |
| Packaging Details | bulk packing, in bundle or by pallet | Grating size | 3'x20', 3'x24',3'x30',1000x1000,1000x5800,1000x6000mm |
| Model Number | GB-007 | Supply Ability | 3000 pcs per day |
| Certification | ISO9001 | Surface treatment | hot dipped galvanized |
| Brand Name | HBGB | Payment Terms | L/C, T/T |
| Raw Material | Q235,SS 304,SS316 | Grating shape | square, rectangle and etc |
| Price | negotiable | Delivery Time | 15-25days |
| Product name | Steel Bar Grating | Minimum Order Quantity | 100pcs |
| Cross bar | 6x6mm; 50mm,100mm | Application | Drain Grating Covers |
Steel plate by the bearing flat steel bar in accordance with certain spacing and cross arrangement,the welded info a metal products with square lattice in the middle;a steel lattice plate is mainly used to make steel structure platform board,ditch cover plate,steel ladder step plate,building ceiling etc.Lattice steel plate applied to alloy building materials,power station,boiler,shipbuilding,petrochemical,chemical and general industrial buildings, municipal construction and other industrial, with light ventilation,skid resistance,strong bearing capacity.beautiful and durable,easy to clean,convenient installation and other advantages
Characteristics of plain steel bar grating:
1. LACQUERING
To again protection layer through the ways of spraying,brushing and soaking.
2. SERVICE LIFE OF HOT GALVANIZING
Coated zinc thickness of 100um,the anticipated life of products in various circumstances.
3. ANTI-ACID AND ALKALI CORROSSION CAPACITY
The range of PH6 to PH12.5,a stable protective film will be formed on the zinc surface.it has good
anti-corrosive property.
Plain bar grating details:
| Common Specification Of Steel Grating | |
| Material Standard |
ASTM A36, A1011, A569, Q235, S275JR,Stainless steel 304, Mild steel & Low carbon steel, etc |
|
Bearing Bar (width*thickness) |
25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10…..100 x10mm etc; I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'',1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1 1/2''x1/8'' etc |
| Bearing Bar Pitch |
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3,32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc. US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc. |
| Twisted Cross Bar Pitch | 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc |
| Surface treatment |
untreated(black), hot-dipped galvanized ,powder coated, electroplate, painting or as per customers’ requirement. |
| Grating Style | Plain / Smooth, Serrated /teeth, I bar, serrated I bar |
| Packing |
1) LCL(less than one container load): packed with plastic film then on the pallets 2) FCL(full container load): nude packing 3) Other special package :according to customers' requirements. |
| Payment Term |
T/T,L/C, Paypal, Western Union, MoneyGram, Credit Card ,D/A,D/P, Trade assurance |
|
Remarks: Other sizes also can be customized according to customers’ requirement. |
|
high strength, light structure with firm grids pressure welded structure and high bearing property, easy suspending installation, beautiful appearance ,durability with hot galvanized finish, good anti-corrosive property, and bright surface, good ventilation, lighting. cooling and anti-explosion. and deposit-proof.
