| Price | negotiable |
| MOQ | 100pcs |
| Delivery Time | 15-25 days |
| Brand | HBGB |
| Place of Origin | China |
| Certification | ISO 9001 |
| Model Number | GB-006 |
| Packaging Details | Steel Pallet or customized |
| Payment Terms | L/C, T/T |
| Supply Ability | 2000 pcs per day |
| Flat bar pitch | 30mm / 40mm / 60mm | Grating panel | W1000mm, L5800 to 7500 mm |
| Place of Origin | China | Bearing bar | 25x2,25x3,25x4,25x4.5,25x5,30x3,30x4,30x4.5,30x5,32x5,40x5,50x5 mm etc |
| Product namee | Serrated Steel Grating | Packaging Details | Steel Pallet or customized |
| Special pitch | 41mmx50mm, 30mmx 50mm, 33mmx 100mm, 33mmx50mm,33mmx38mm, 34mm x 100mm, 34mmx50mm,34mm x 38mm | Model Number | GB-006 |
| Raw material | Carbon Steel Q 195, 235 | Grating Style | Plain / Smooth, Serrated /teeth, I bar, serrated I bar |
| Supply Ability | 2000 pcs per day | Certification | ISO 9001 |
| Surface treatment | Black, self color, hot dip galvanized, painted, spray coating | Brand Name | HBGB |
| Payment Terms | L/C, T/T | Price | negotiable |
| Delivery Time | 15-25 days | Minimum Order Quantity | 100pcs |
| Loading port | tianjin port | Finishing | hot dipped galvanized or powder coated, painted |
Steel
grating
is
manufactured
using
an
electro-forgewelding
process
that
applies
pressure
and
heat
to
fuse
square,
twisted
cross
bars
into
load-bearing
bars
of
various
thicknesses
and
depths.
The
result
is
a
product
of
one-piece
construction
that
complies
with
AS1657-2013.
The
press
welded
galvanized
steel
grating/grille/grate
is
made
of
load
flat
steel
bar
and
cross
bar,
placed
horizontally
and
vertically,
and
at
an
equal
pitch
apart,
by
welding
with
200-ton
hydraulic
resistance
automatic
welding
equipment,
then
cutting,
punching
and
banding
ends.
Hot Dipped Galvanized standard of steel grating:
Normally,Hot galvanizing will be carried out after end welding process,For the thickness of bearing bars is not less than 5mm,the weight of average Zinc Layer will not be less than 610g/m2.When the thickness of bearing bars is less than 5mm,the weight of average Zinc Layer
Will not be less than 460g/m2. The quality and requirements after hot galvanizing are subject to the standards of GB/T 13912.
1. Steel flat bar 2. Twist bar 3. Punching 4. Welding 5. Acid picking 6. Galvanizing 7. Inspecting 8. packing 9. delivering
|
Bearing
Bar
|
25x2,25x3,25x4,25x4.5,25x5,30x3,30x4,30x4.5,30x5,32x5,40x5,50x5
mm
etc
|
||
|
Usual
Pitch
|
41mm
x100mm
&
30mm
x100mm
|
||
|
Special
Pitch
|
41mmx50mm,
30mmx
50mm,
33mmx
100mm,
33mmx50mm,33mmx38mm,
34mm
x
100mm,
34mmx50mm,34mm
x
38mm
|
||
|
Material
Standard
|
Q235,ASTMA36,A1011,A569,S275JR,SS304&316
etc
|
||
|
Surface
Treatment
|
galvanized,black,painted,spray
coating,self
color
|
||
|
Bearing
Bar
Type
|
serrated/teeth
plain/smooth
I
bar
Serrated
I
bar
|
||
|
HS
code
|
7308900000
|
||
|
Sample
|
small
pc
for
free
|
||
Applications
of
galvanized
serrated
steel
bar
grating:
Galvanizing
steel
grating
/
grille
/
grate
is
widely
used
in
the
platform,
corridor,
bridge,
well
covers,
stairs,fencing
for
petroleum,
chemical,
power
plant,
waste
treatment
plant,
civil
engineering
projects
and
environmental
projects.
