| Price | $1,000.00 - $16,000.00/Sets |
| MOQ | 1 SET |
| Delivery Time | 30 work days |
| Brand | ZHEN HAI |
| Place of Origin | LANGXI,ANHUI,CHINA |
| Certification | ISO9001, CE |
| Model Number | HFJ-26F-2 |
| Packaging Details | polywood case/ plastic films |
| Payment Terms | T.T., L/C, Western Union, MoneyGram |
| Supply Ability | 100 sets/year |
| Place of Origin | LANGXI,ANHUI,CHINA | Warranty | 1 Year |
| Max Sewing Speed | 2200r/m | Packaging Details | polywood case/ plastic films |
| After-sales Service Provided | Free spare parts, Video technical support, Online support, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas | Dimension(L*W*H) | 3450*4220*1780MM |
| Model Number | HFJ-26F-2 | Supply Ability | 100 sets/year |
| Certification | ISO9001, CE | Weight | 1820KG |
| Brand Name | ZHEN HAI | Payment Terms | T.T., L/C, Western Union, MoneyGram |
| Price | $1,000.00 - $16,000.00/Sets | Delivery Time | 30 work days |
| Moving Style | Head Moved | Minimum Order Quantity | 1 SET |
| Number of Head | Single Head | Voltage | 220v,50hz,single phase |
| Max Sewing Thickness | 1500gsm | Power | 2.0kW |
2200r/m
Mattress
Quilting
Sewing
Machine
High
Precision
Low
Noise
HFJ-26F-2
Specifications
1) 19"LCD
with Chinese and English version. With 538
patterns already in the computer; lockstitch, high precision
2) Power supply: 220V, 50Hz, 2kw
3) Automatically stops if thread breaks
4) Automatically stop against malfunction of computer, motor, and display
5) Pattern form: .DST, .DAT
6) USB interface
7) Single stitch length:2-7mm
8) Needle type: DP5 18~22#
9) Max. speed: 2200rpm,
special
can
reach
2500rpm
with
servo
motor
equipped
for
machine
head
10) Max. thickness: 1500 gsm
Quilting Production Line Including
Usages
Suitable
for
quilting
patterns
on
duvet,
mattress
pad,
bedcover,
garments,
etc.
Can
also
quilt
on
sponge
and
leather.
| HFJ-26F-2 | HFJ-28F-2 | HFJ-30F-2 | HFJ-32F-2 | HFJ-35F-2 | |
| Max quilt size | 2400×2600mm | 2600×2800mm | 2800×3200mm | 3000×3200mm | 3200×3500mm |
| Max needle drop size | 2200×2400mm | 2400×2600mm | 2600×3000mm | 2800×3000mm | 3000×3300mm |
| Machine dimension | 5000×3420×1780mm | 5200×3700×1780mm | 5600×3900×1780mm | 5600×4100×1780mm | 5900×4220×1780mm |
| Thread type | LOCK STITCH | LOCK STITCH | LOCK STITCH | LOCK STITCH | LOCK STITCH |
| Max quilting speed | 2200rpm | 2200rpm | 2200rpm | 2200rpm | 2200rpm |
| Max quilting thickness | 1500gsm | 1500gsm | 1500gsm | 1500gsm | 1500gsm |
| Stitch length adjustment | 2-7mm | 2-7mm | 2-7mm | 2-7mm | 2-7mm |
| Needle model | DP5 18-22# | DP5 18-22# | DP5 18-22# | DP5 18-22# | DP5 18-22# |
| Pattern format | .DAT, .DST | .DAT, .DST | .DAT, .DST | .DAT, .DST | .DAT, .DST |
| USB | YES | YES | YES | YES | YES |
| Thread break detection | YES | YES | YES | YES | YES |
| Monitor | 19" LCD | 19" LCD | 19" LCD | 19" LCD | 19" LCD |
| Voltage | 220V/ 50HZ | 220V/ 50HZ | 220V/ 50HZ | 220V/ 50HZ | 220V/ 50HZ |
| Power | 2.0KW | 2.0KW | 2.0KW | 2.0KW | 2.0KW |
| Packing dimension | 3590×760×1770mm | 3890×760×1770mm | 4090×760×1770mm | 4290×760×1770mm | 4390×760×1770mm |
| G.W./N.W. | 1440kg/1300kg | 1580kg/1440kg | 1660kg/1520kg | 1750kg/1600kg | 1820kg/1700kg |
Finished Products
1, wooden case/polywood case
2, plastic foam packing
3, nude packing
1,How to contact you?
You could contact us via TM,wechat, QQ, email or call us directly.
2,Are you factory or trading company?
We are factory with foreign trading property. That is to say,we produce machines and we export to customers by ourself.
3,How many countries have your products been exported to?
Until now our machines have been already exported to more than 100 countries.Welcome to visit us.
4,Which payment term is accepted?
30% in advanced payment by T.T and 70% paid before shipment by T.T.
Welcome for your inspection for the machines before shipment.
5,Can you make speicial voltage of the machines?
yes,usually the machines are made with 380v,50hz,3 phases or 220v,50hz,single phases.If you need special, please inform us and we customized.
