| Price | Negotiable |
| MOQ | 1pcs |
| Delivery Time | 3-8 work days |
| Brand | KHJ |
| Place of Origin | Guangdong, China |
| Certification | CE,RoHS |
| Model Number | KBB80, KBB100, KBB120, KBB150 |
| Packaging Details | 420*420*185mm |
| Payment Terms | L/C, T/T |
| Supply Ability | 400pcs per day |
| Place of Origin | Guangdong, China | Packaging Details | 420*420*185mm |
| Product Name | Brownbear series | Model Number | KBB80, KBB100, KBB120, KBB150 |
| Supply Ability | 400pcs per day | Certification | CE,RoHS |
| Brand Name | KHJ | Payment Terms | L/C, T/T |
| THD | ＜10% | Price | Negotiable |
| Delivery Time | 3-8 work days | Operating Voltage | 100-277 VAC， 141-391VDC |
| Minimum Order Quantity | 1pcs | Frequency | 50/60Hz |
| Power Factor | ＞0.98 | Lifespan | >50,000 hours |
| Power | 80W,,120W,150W | Luminaire Efficacy | 142lm/W |
High quality and reliable Industrial LED High Bay Light Brownbear series 80W 120W 150W IP66
Brownbear Series LED high bay Light 80W 120W 150W
Highlight: Industrial high bay light
Features And Benefits:
1. Durable LED high bay light fixture, highly efficient, long-lifespan and innovative.
2. High efficacy Led source, whole luminaire efficacy up to 135lm/w.
3. Strong die-cast aluminum alloy housing and tempered glass, Impact and shock resistance.
4. Optional luminous intensity distribution for different applications.
5. Meanwell Led driver.
6. 6KV Surge protection.
7. Ambient temperature from -40℃ to 55℃.
8. 5 Years performance warranty.
Product Differentiation:
| Standards |
EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
| Certificate | CE, RoHS |
| Ambient temp | -40℃ ≤ Ta ≤ +65℃ |
| Ingress Protection | IP66 |
| Cable entry | M25*1.5(M20*1.5,3/4 NPT for optional) |
Applications:
Brownbear durable industrial LED high bay light can be widely used for all non-hazardous area:
Power generation industry
Stadium lighting
Machine manufacturing
Factories
Warehouse
Large scale infrastructure
Ordering
information:
| P/N | Operating Voltage(V) | Luminous Flux(lm) | Power(W) | CRI | Color Temp. | CCT(K) |
| KBB80*WM-E |
100-277 AC (141-392 DC) |
10500 | 80 | 70 | Warm white | 3000±300 |
| KBB80*NH-E | 11340 | 80 | 70 | Natural white | 4000±300 | |
| KBB80*NH-E | 11340 | 80 | 70 | Natural white | 5000±300 | |
| KBB80*CH-E | 11340 | 80 | 70 | Cool white | 5700±300 | |
| KBB100*WM-E | 13125 | 100 | 70 | Warm white | 3000±300 | |
| KBB100*NH-E | 14175 | 100 | 70 | Natural white | 4000±300 | |
| KBB100*NH-E | 14175 | 100 | 70 | Natural white | 5000±300 | |
| KBB100*CH-E | 14175 | 100 | 70 | Cool white | 5700±300 | |
| KBB120*WM-E | 15750 | 120 | 70 | Warm white | 3000±300 | |
| KBB120*NH-E | 17010 | 120 | 70 | Natural white | 4000±300 | |
| KBB120*NH-E | 17010 | 120 | 70 | Natural white | 5000±300 | |
| KBB120*CH-E | 17010 | 120 | 70 | Cool white | 5700±300 | |
| KBB150*WM-E | 19687 | 150 | 70 | Warm white | 3000±300 | |
| KBB150*NH-E | 21262 | 150 | 70 | Natural white | 4000±300 | |
| KBB150*NH-E | 21262 | 150 | 70 | Natural white | 5000±300 | |
| KBB150*CH-E | 21262 | 150 | 70 | Cool white | 5700±300 |
Remarks:
1. * Stands for beam angle,including H5V5 / H6V6/FW
2. For Beam angle H5V5,the luminous flux will be 15% less
3. For Beam angle FW,the luminous flux will be 30% less
