| Price | Negotiable |
| MOQ | 1pcs |
| Delivery Time | 3-8 work days |
| Brand | KHJ |
| Place of Origin | Guangdong, China |
| Certification | ATEX, CE,RoHS |
| Model Number | Ex-KFIF12,Ex-KFIF24,Ex-KFIF35 |
| Payment Terms | L/C, T/T |
| Supply Ability | 400pcs per day |
| Place of Origin | Guangdong, China | Product Name | Firefly Series |
| Model Number | Ex-KFIF12,Ex-KFIF24,Ex-KFIF35 | Supply Ability | 400pcs per day |
| Certification | ATEX, CE,RoHS | Brand Name | KHJ |
| Payment Terms | L/C, T/T | THD | ＜10% |
| Price | Negotiable | Delivery Time | 3-8 work days |
| Operating Voltage | 100-277 VAC,141-392 VDC | Minimum Order Quantity | 1pcs |
| Area Classification | Group II Zone 1 & 21 and 2 & 22 | Power Factor | ＞0.98 |
| Lifespan | >50,000 hours | Power | 12W,24W,35W |
| Luminaire Efficacy | 136.5lm/W |
12W
24W
35W
LED
explosion
proof
lights
strong
tempered
glass
Firefly
Series
LED explosion proof lights Zone1
12W 24W 35W
Firefly Series
Highlight: LED explosion proof light
Features And Benefits:
1. High efficacy LED Source with long lifespan>50,000 hours.
2. High strength aluminum alloy housing.
3. 5KV surge protection.
4. 5-year performance warranty.
5. Life span> 50,000 hours.
6. Ambient temperature from -40℃to 55℃.
Ex Mark:
Gas: II 2 G Ex db op is IIC T5 or T6 Gb
Dust: II 2 D Ex tb op is IIIC T95°C or T80°C Db IP66
Certificate: ATEX Certification NO.:EPT 18 ATEX 2977 X, CE, RoHS
Executive Standard:
EN 60079-0:2018,EN 60079-11:2012,EN 60079-31:2014
EN 60079- 1:2014,EN 60079-18:2015+A1:2017 ,IEC 60079-0:2018
EN 60079-7:2015+A1:2018,EN 60079-28:2015
| Electrical & Photometric Features: | |
| Luminaire Efficacy: | 136.5lm/W |
| Lifespan: | >50,000 hours |
| Operating Voltage: |
100-277 VAC 141-392 VDC |
| Power(W): | 12W/24W/35W |
| Frequency: | 50/60Hz |
| Power Factor: | ＞0.98 |
| THD: | ＜10% |
| Insulation Class: | Ⅰ |
| Surge Protection: | 5KV |
| LED Driver: | Over voltage protection/short circuit protection |
| Mechanical Features: | |
| Weight: | 2.4Kg(Junction box),2.6Kg(Stanchion junction box) |
| Size: | φ136*210mm(Junction box),φ136*194mm(Stanchion junction box) |
| Ambient Temperature: | -40℃-+55℃ |
| Connecting Terminals: | 3*1.0-4mm²(L+N+PE) |
| Available cable outer diameter: | φ7-φ14(mm) |
| Cable Entries: | 1XNPT 3/4” (M20*1.5, M25*1.5 are optional) |
| Earthing Protection: | M4 (Internal & external earth bolts) |
| IP Code: | IP66 |
| Enclosure Material: | Die-casting aluminium alloy |
| Enclosure Colour: | Orange,RAL2011(optional grey RAL7040) |
| Coating: | Epoxy powder coating |
| Exposed Fastener: | Stainless steel |
| Protective Cover: | Tempered glass,Stand 7J impact |
Applications:
LED Explosion Proof Lights suitable for hazardous applications as follows:
1.Drilling
2.Oil&Gas
Exploration
3.Petrochemical
Plant
4.Power
Plant
5.Pharmaceutical
Plant
Ordering
information:
|
P/N |
Operating Voltage(V) |
Luminous Flux(lm) |
Power (W) |
CRI |
Color Temp. |
CCT(K) |
Temp. Classification |
|
-40℃ ~+55℃ |
|||||||
| Ex-KFIF12H6V6WM-*-E |
100~277 AC (141~392 DC) |
1512 | 12 | 80 | Warm white | 3000±300 |
T6 |
| Ex-KFIF12H6V6NH-*-E | 1638 | 12 | 70 | Natural white | 4000±300 | ||
| Ex-KFIF12H6V6NH-*-E | 1638 | 12 | 70 | Natural white | 5000±300 | ||
| Ex-KFIF12H6V6CH-*-E | 1638 | 12 | 70 | Cool white | 5700±300 | ||
| Ex-KFIF24H6V6WM-*-E | 3024 | 24 | 80 | Warm white | 3000±300 | ||
| Ex-KFIF24H6V6NH-*-E | 3276 | 24 | 70 | Natural white | 4000±300 | ||
| Ex-KFIF24H6V6NH-*-E | 3276 | 24 | 70 | Natural white | 5000±300 | ||
| Ex-KFIF24H6V6CH-*-E | 3276 | 24 | 70 | Cool white | 5700±300 | ||
| Ex-KFIF35H6V6WM-*-E | 4410 | 35 | 80 | Warm white | 3000±300 |
T5 |
|
| Ex-KFIF35H6V6NH-*-E | 4778 | 35 | 70 | Natural white | 4000±300 | ||
| Ex-KFIF35H6V6NH-*-E | 4778 | 35 | 70 | Natural white | 5000±300 | ||
| Ex-KFIF35H6V6CH-*-E | 4778 | 35 | 70 | Cool white | 5700±300 |
