| Price | Negotiable |
| MOQ | 1pcs |
| Delivery Time | 3-8 work days |
| Brand | KHJ |
| Place of Origin | Guangdong, China |
| Certification | ATEX,IECEx,CE,RoHS |
| Model Number | Ex-KPLB80 |
| Packaging Details | 485*265*250mm |
| Payment Terms | L/C, T/T |
| Supply Ability | 400pcs per day |
| Place of Origin | Guangdong, China | Packaging Details | 485*265*250mm |
| Product Name | Polar Bear Series | Model Number | Ex-KPLB80 |
| Supply Ability | 400pcs per day | Certification | ATEX,IECEx,CE,RoHS |
| Brand Name | KHJ | Payment Terms | L/C, T/T |
| Price | Negotiable | Delivery Time | 3-8 work days |
| Operating Voltage | 100-130 VAC, 220-240 VAC/141-184 VDC, 311-339 VDC | Minimum Order Quantity | 1pcs |
| Area Classification | Group II Zone 2 & 22 | Frequency | 50/60Hz |
| Power Factor | ＞0.98 | Lifespan | >50,000 hours |
| Power | 80W | Luminaire Efficacy | 147m/W |
80W ATEX & IECEx Explosion Proof LED Flood Light Polar Bear Series
80W ATEX & IECEx certified Explosion Proof LED Flood Light for hazardous area Zone 2 Polar Bear Series.
Highlight: ATEX& IECEx Explosion Proof LED floodlight, 80W Explosion Proof LED lighting.
Features And Benefits:
1. High efficacy LED Source with long lifespan>50,000 hours.
2. Copper-free aluminium alloy housing.
3. Strong tempered glass.
4. Power factor > 0.98.
5. 5KV surge protection.
6. Ambient temperature from -40℃to 55℃.
7. THD < 10%.
Product Important Information:
| Type Of Protection | Ex nR,Ex tc | |||||||
| Protection Standards |
(IEC)EN 60079-0, (IEC)EN 60079-15,(IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
|||||||
| Area Classfiction |
Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1, Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2 |
|||||||
| Installation | (IEC)EN 60079-14 | |||||||
| Certificate | IECEx CQM 13.0044X | LCIE 14 ATEX 1014 X | ||||||
| Equipment Coding |
Ex nR IIC T4 or T5 or T6 Gc Ex tc IIIC T130℃ or T95℃ or T80℃ Dc IP66 |
Ex nR IIC T* Gc Ex tc IIIC T* Dc IP66 |
||||||
| Temperature Class | Rated Power | Rated Voltage | -40℃ ≤ Ta ≤ +40℃ | -40℃ ≤ Ta ≤ +55℃ | ||||
| Gas | Dust | Gas | Dust | |||||
| 80W |
100~130VAC 220~240VAC 50/60Hz |
T6 | T80℃ | T5 | T95℃ | |||
| ATEx Coding |
 II
2
G
/
II
2
D
|
|||||||
| Ingress Protection | IP66 (IEC)EN 60529 | |||||||
| Cable entry | M20*1.5 or M25*1.5 and 3/4 NPT | |||||||
| CE Mark |
The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements |
|||||||
Applications
LED Explosion Proof Flood Light.
Suitable for hazardous applications such as drilling, oil refinery, petrochemical plant etc.
Ordering
information:
|
P/N |
Operating Voltage(V) |
Luminous Flux(lm) |
Power(W) |
CRI |
Color Temp. |
CCT(K) |
Temp. Classification |
| Ex-KPLB80*WM-E |
100-277 AC (141-392 DC) |
10920 | 80 | 70 | Warm white | 3000±300 | T6/T5 |
| Ex-KPLB80*NH-E | 11760 | 80 | 70 | Natural white | 4000±300 | T6/T5 | |
| Ex-KPLB80*NH-E | 11760 | 80 | 70 | Natural white | 5000±300 | T6/T5 | |
| Ex-KPLB80*CH-E | 11760 | 80 | 70 | Cool white | 5700±300 | T6/T5 |
Remarks:
1. * Stands for beam angle,including H1V1 / H4V4 / H5V5 / H6V6 / SL/FW;
2. For Beam angle H1V1,H4V4 and H5V5,the luminous flux will be 15% less;For Beam angle SL/FW,the luminous flux will be 30% less.
