| Price | Negotiable |
| MOQ | 1 pcs |
| Delivery Time | 3-8work days |
| Brand | KHJ |
| Place of Origin | Guangdong, China |
| Certification | ATEX,IECEx,CE,RoHS |
| Model Number | Ex-KFF30,Ex-KFF45,Ex-KFF60 |
| Packaging Details | 275*275*230mm |
| Payment Terms | L/C, T/T |
| Supply Ability | 400pcs/day |
| Place of Origin | Guangdong, China | LED Driver | Over voltage protec |
| Packaging Details | 275*275*230mm | Model Number | Ex-KFF30,Ex-KFF45,Ex-KFF60 |
| Supply Ability | 400pcs/day | Certification | ATEX,IECEx,CE,RoHS |
| Ambient Temperature | -40℃-+55℃ | Brand Name | KHJ |
| Payment Terms | L/C, T/T | Connecting Terminals | 3*1.0-4mm²(L+N+PE) |
| Surge Protection | 5KV | Price | Negotiable |
| Delivery Time | 3-8work days | Product name | ForestFrog Series Zone 1 Explosion Proof Lighting |
| Operating Voltage | 24-48 VAC/100-277 VAC/10-30 VDC/24-48 VDC/141-392 VDC | Minimum Order Quantity | 1 pcs |
| Frequency | 50/60Hz | Power | 30W,45W,60W |
ForestFrog Series ATEX & IECEx Certified Zone 1 Explosion Proof Lighting in Hazardous Area.
This user manual covers the range of ATEX and IECEx ForestFrog series LED luminaire. These luminaires areconstructed with corrosion resistant epoxy coated Die-casting aluminium alloy body and high impact resistance tempered glass diffuser.
ForestFrog series LED are available from30W to 60W, providing ideal solutions for a wide range of harsh and hazardous applications.
Features
And
Benefits:
1.
High
efficacy
LED
Source
with
long
lifespan>50,000
hours.
2.
5-year
performance
warranty.
3.
Low
THD
around
10%,Less
interference.
4.
5KV
Surge
Protection.
5.
Robust
aluminium
housing
and
strong
tempered
glass.
6.
Vibration
and
shock
resistant.
7.
Low
maintenance.
Product Important Information:
| Type Of Protection | Ex db, Ex db eb, Ex tb | ||||
| Protection Standards |
(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-7, (IEC)EN 60079-28, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
||||
| Area Classfiction | Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2 | ||||
| Installation | (IEC)EN 60079-14 | ||||
| Certificate | EPT 18 ATEx 2977 X | ||||
| Equipment Coding |
Ex db op is IIC T* Gb,Ex tb op is IIIC T* Db Ex db eb op is IIC T* Gb,Ex tb op is IIIC T* Db |
||||
| Temperature Class | Rated power (W) | -40℃ ≤ Ta ≤ +40℃ | -40℃ ≤ Ta ≤ +55℃ | ||
| Gas | Dust | Gas | Dust | ||
| 30W | T6 | T80℃ | T5 | T95℃ | |
| 45W | T6 | T80℃ | T5 | T95℃ | |
| 60W | T5 | T95℃ | T4 | T130℃ | |
| ATEx Coding |
 II
2
G
/
II
2
D
|
||||
| Ingress Protection | IP66 (IEC)EN 60529 | ||||
| Cable entry | M20*1.5 or M25*1.5 and 3/4 NPT | ||||
| CE Mark |
The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements |
||||
Electrical Supplies:
| Size:Ø220*102mm | |||||||||
| Voltage Range(AC) | 100-277VAC (standard) | 24-48VDC/VAC | 10-30VDC | ||||||
| Frequency Range(Hz) | 50/60Hz | 50/60Hz | |||||||
| Power Watts(W) | 30W | 45W | 60W | 30W | 45W | 60W | 30W | 45W | 60W |
| Standard Current Range(A) | 0.1~0.3 | 0.16~0.45 | 0.21~0.6 | 0.6~1.25 | 0.9~1.9 | 1.25~2.5 | 1~3 | 1.5~4.5 | 2~6 |
Luminaire
Efficacy:
136.5lm/W
Lifespan:>50,000
hours
Operating
Voltage:
24-48
VAC/100-277
VAC
10-30 VDC/24-48 VDC/141-392 VDC
Power:30W,45W,60W
Frequency:50/60Hz
Power
Factor:
＞0.98
THD:＜10%
Insulation
Class:
Ⅰ
Surge
Protection:
5KV
LED
Driver:
Over
voltage
protection/short
circuit
protection
Weight:3.3Kg
Size:φ220*191mm
Ambient
Temperature:
-40℃-+55℃
Connecting
Terminals:
3*1.0-4mm²(L+N+PE)
Available
cable
outer:φ7-φ14(mm)
Cable
Entries:
2XNPT
3/4”
(M20*1.5,M25*1.5
are
optional)
Earthing
Protection:
M4
(Internal
&
external
earth
bolts)
IP
Code:
IP66
Enclosure
Material:
Die-casting
aluminium
alloy
Enclosure
Colour:
Orange,RAL2011(optional
grey
RAL7040)
Coating:
Epoxy
powder
coating
Exposed
Fastener:
Stainless
steel
Protective
Cover:
Tempered
glass,Stand
7J
impact
Applications:
1.
Oil&Gas
Exploration
2.
Drilling
3.
Oil
Refinery
4.
Petrochemical
Plant
5.
Power
Plant
6.
Pharmaceutical
Plant
Ordering
Information:
|
P/N |
Operating Voltage(V) |
Luminous Flux(lm) |
Power (W) |
CRI |
Color Temp. |
CCT(K) |
Temp. Classification | |
| -40℃~+40℃ | -40℃~+55℃ | |||||||
| Ex-KFF30*WM-J-E |
100~277 AC (141~392 DC) |
3780 | 30 | 70 | Warm white | 3000±300 | T6 | T5 |
| Ex-KFF30*NH-J-E | 4095 | 30 | 70 | Natural white | 4000±300 | T6 | T5 | |
| Ex-KFF30*NH-J-E | 4095 | 30 | 70 | Natural white | 5000±300 | T6 | T5 | |
| Ex-KFF30*CH-J-E | 4095 | 30 | 70 | Cool white | 5700±300 | T6 | T5 | |
| Ex-KFF45*WM-J-E | 5670 | 45 | 70 | Warm white | 3000±300 | T6 | T5 | |
| Ex-KFF45*NH-J-E | 6142 | 45 | 70 | Natural white | 4000±300 | T6 | T5 | |
| Ex-KFF45*NH-J-E | 6142 | 45 | 70 | Natural white | 5000±300 | T6 | T5 | |
| Ex-KFF45*CH-J-E | 6142 | 45 | 70 | Cool white | 5700±300 | T6 | T5 | |
| Ex-KFF60*WM-J-E | 7560 | 60 | 70 | Warm white | 3000±300 | T5 | T4 | |
| Ex-KFF60*NH-J-E | 8190 | 60 | 70 | Natural white | 4000±300 | T5 | T4 | |
| Ex-KFF60*NH-J-E | 8190 | 60 | 70 | Natural white | 5000±300 | T5 | T4 | |
| Ex-KFF60*CH-J-E | 8190 | 60 | 70 | Cool white | 5700±300 | T5 | T4 | |
Remarks:
1. *Stands for candela distribution, including H1V1 / H5V5 / H6V6/F/FW.
2. For beam angle H1V1/H5V5,the luminous flux will be 8% less.
3. For beam angle FW/F,the luminous flux will be 25% less.
Candela
Distribution:
Installation
Method:
