| Price | Negotiation |
| MOQ | 1 set |
| Delivery Time | 15-90 work days |
| Brand | JWIM |
| Place of Origin | made in China |
| Certification | CE,CO,ISO |
| Model Number | DGD-280A（Double Hopper） |
| Packaging Details | Wooden cases |
| Payment Terms | L/C, T/T |
| Supply Ability | 1 set per month |
| Place of Origin | made in China | Filling Precision | ±1g(100g)；≤±2g(200-300g)；≤±3g(300-500g)；≤±3g(500-1000g) |
| Productive Power. | 16-35 bags / min | Packaging Details | Wooden cases |
| Air Pressure | 0.5-0.7MPA 500L/min | Packaging Capacity | ≤1000g |
| Material | SUS304 | Model Number | DGD-280A（Double Hopper） |
| Supply Ability | 1 set per month | High Light | 50 gm 1kg Automatic Bag Filling And Sealing Machine Edible Oil Pouch Packing Machine |
| Certification | CE,CO,ISO | Weight | About 3100kg |
| Applicable Bag Size | W120-280mm L180-380mm | Brand Name | JWIM |
| Payment Terms | L/C, T/T | Equipment Size | 3665×2420×2800mm(L×W×H) |
| Price | Negotiation | Delivery Time | 15-90 work days |
| Minimum Order Quantity | 1 set | Model | DGD-280A（Double Hopper） |
| Power | AC380V 50Hz/5.5KW |
50g-1000g Prefabricated Bag Granule Automatic Pouch Packaging Machine Double Hopper
1. Introduction of Automatic Pouch Packaging Machine
DGD-280A
full-automatic
horizontal
bag
feeding
bagging
machine
is
our
in-line
online
weighing
bagging
machine,
which
can
be
equipped
with
an
online
weighing
and
filling
function
and
vacuum
pumping
function.
The
whole
machine
includes
a
bag-taking
mechanism,
bag
opening
mechanism,
air
blowing
mechanism,
filling
mechanism,
heat
sealing,
cold
sealing, and
shaping
mechanism.
The
coordinated
action
of
each
mechanism
is
completed
through
the
mechanical
connecting
rod
and
cam
structure.
Under
the
programmable
control
of
PLC,
the
functions
of
bag-taking
→
bag
opening
→
detection
→
filling
1
→
filling
2
(optional
weighing)
→
sealing
→
finished
product
are
realized.
The
machine
has
a
reasonable
design,
novel
appearance,
and
complete
dust
removal
system,
which
meets
the
production
requirements
of
safety
and
environmental
protection.
At
the
same
time,
by
changing
the
filler,
the
automatic
filling
of
powder,
particle,
water
agent,
suspension
agent,
and
other
materials
can
be
realized
on
the
machine.
It
is
applicable
to
the
packaging
production
of
all
kinds
of
prefabricated
bag
products.
2. Parameters of DGD-280A (Double Hopper) Pouch Packing Machine
| Productive Power. | 16-35 bags / min |
| Applicable Bag Size | W120-280mm L180-380mm |
| Packaging Capacity | ≤1000g |
| Filling Precision | ±1g(100g)；≤±2g(200-300g)；≤±3g(300-500g)；≤±3g(500-1000g) |
| Air Pressure | 0.5-0.7MPA 500L/min |
| Power | AC380V 50Hz/5.5KW |
| Equipment Size | 3665×2420×2800mm(L×W×H) |
3. Features of Prefabricated Bag Packing Machine
a) The equipment is suitable for the production of all kinds of prefabricated bags, with beautiful packaging and molding.
b) High capacity: linear structure, easy maintenance, high speed, 30% faster than the capacity of the rotary bagging machine.
c) Environmentally friendly: a material collection tank is added under the blanking device of the host machine (convenient for manual cleaning and material recycling).
d) High precision: rough filling and filling while weighing are adopted to ensure the high precision of products. (Optional functional module)
