| Price | From $12,000 (final price depends on configuration & volume) |
| MOQ | 1 |
| Delivery Time | 5 working days |
| Brand | SYSEYE |
| Place of Origin | China |
| Certification | FDA 510(k): K190954 |
| Model Number | RetiCam 3100 |
| Packaging Details | 380mm(L)x550mm(W)x475mm(H) |
| Payment Terms | ,T/T |
| Supply Ability | 100 |
| Working Distance | 35mm | Place of Origin | China |
| Packaging Details | 380mm(L)x550mm(W)x475mm(H) | Minimum Pupil | ≥3.3 mm |
| Model Number | RetiCam 3100 | Supply Ability | 100 |
| Certification | FDA 510(k): K190954 | Weight | 26.5Kg |
| Brand Name | SYSEYE | Payment Terms | ,T/T |
| Focus Modes | Manual/Auto | Price | From $12,000 (final price depends on configuration & volume) |
| Delivery Time | 5 working days | Product name | High Resolution Digital Fundus Camera |
| Minimum Order Quantity | 1 | Stage | 90 mm left and right, 35 mm front and rear |
| Magnification | 1.3 | Field of View | 50° |
| Field of view | 50° (typical) |
| Minimum pupil diameter | ≥3.3 mm (small-pupil mode) |
| Resolution (lp/mm) | Center ≥60 | Edge ≥25 |
| Magnification | 1.3* |
| Working distance | 35 mm |
| Focus system | Auto/manual with ±25 D compensation |
| Alignment | XYZ auto-alignment |
| Illumination | IR LED for observation | Xenon flash for capture |
| Fixation | Internal LED with external fixation support |
| Movement range | Stage: 90mm (L/R), 35mm (F/B) Main unit: 30mm vertical Chin-rest: 60mm |
| Power supply | AC 100-240 V, 50/60 Hz |
| Dimensions/Weight | 380*550*475 mm / 26.5 kg |
