CEMS Online Infrared Syngas Analyzer O2 Trace Analyzer

Price	Negotiable
MOQ	1 set
Delivery Time	in stock
Brand	Zetron
Place of Origin	China
Certification	CE/Atex
Model Number	ZN301
Packaging Details	paper box
Payment Terms	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Product Details

Product Specification

product name	ZN301 plug in trace oxygen analyzer	Place of Origin	China
measuring range	0.0～10/100/1000×10-6 O2	Packaging Details	paper box
weight	4.5kg	Model Number	ZN301
resolution	0.1×10-6	Certification	CE/Atex
Brand Name	Zetron	Payment Terms	L/C, D/A, D/P, T/T, Western Union, MoneyGram
size	270mmx132mmx320mm	Delivery Time	in stock
response time	T90< 15 sec	Minimum Order Quantity	1 set

Product Description

Zetron ZN301 Online Trace Oxygen Analyzer

OVERVIEW

ZN301 Trace Oxygen Analyzer is a new-type intelligent industrial online analyzer researched and developed by combining imported high-performance electrochemical sensor with new microcomputer technology based on the principles of electrochemical detection.

FEATURES

Imported fuel cell sensor adopted, featuring long service life, high accuracy, and quick response;
Chinese human-machine dialog menu, making operation intuitive and convenient;
Timed automatic storing function, and stored data available for viewing at any time;
Automatic range shifting; alarm point can be set at will within the whole range;
Standard RS232 or RS485 communication interface available for two-way communication with computer;
Built-in air extracting pump and external filter can be added upon selection;
Type B adopts economical 128×64 lattice LCD; type C uses engineering 320×240 lattice LCD; and type D employs intelligent 800×400 touch screen in combination with embedded RAM technical instrument

SPECIFICATION

Measurement range	0.0～10/100/1000×10^-6 O₂
Accuracy	≤±5% F.S (0.0～10×10^-6); ≤±2% F.S (10～100×10^-6); ≤±2% F.S (100～1000×10^-6)
Resolution	≤ ±1%
Stability	Zero drift ≤ ±2% FS/7d; Span drift ≤ ±2% FS/7d
Response time	90 ≤ 15 sec
Sample gas flow	400±10 ml/min
Sample gas pressure	0.05 MPa ≤ Inlet Pressure ≤ 0.25 MPa;
Output signal	4～20 mA
Operating environment	Temperature: －5℃～＋45℃; Humidity: ≤ 90% RH;
Operating power supply	1. 220 VAC±10%, 50 Hz±5%; 2. Rechargeable lithium-ion battery built in the instrument;
Overall dimensions	Type B: 270 mm (W) × 132 mm (H) × 330 mm (D); Type C 3U: 485 mm (W) × 133.5 mm (H) × 360 mm (D); Type D 4U: 485 mm (W) × 178 mm (H) × 360 mm (D);
Weight	Type B: about 3 kg; type C: about 8 kg; type D: about 10 kg

APPLICATION

Online analysis on oxygen content in protective gases for high-temperature sintering furnaces of nitrogen production by air separation, chemical process, magnetic materials, and so on; in protective gases for electronic industry; and in glass and building material industries.
