Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off

Price	Negotiable
MOQ	10
Delivery Time	5-7 Days
Brand	Tian Rui
Place of Origin	China
Certification	ROHS
Model Number	QB-0060/6006
Packaging Details	1PCS/Bag
Payment Terms	D/P, T/T,Paypal, Visa, Mastercard
Supply Ability	1000000PCS/Month

Product Details

Product Specification

Mounting Holes	Accept #10 Screw	Place of Origin	China
Packaging Details	1PCS/Bag	Product Name	Boat Marine RV Battery Switch
Switch Type	Single Circuit ON-OFF	Model Number	QB-0060/6006
Starting Rating 30 sec	900A	Battery Inputs	1
Supply Ability	1000000PCS/Month	Certification	ROHS
Rated Voltage	48V DC	Brand Name	Tian Rui
Payment Terms	D/P, T/T,Paypal, Visa, Mastercard	Stud Size	3/8"
Price	Negotiable	Delivery Time	5-7 Days
Cable Size to Meet Ratings	4/0 AWG (120mm²)	Minimum Order Quantity	10
Rated Current	300A	Stud Material	Tinned Copper
Intermittent Rating	500A (5 min)	Switch Posistions	2

Product Description

2 Position Cut Off 32V 48V DC Marine Boat Yacht RV 6006 Battery Isolator Switch Disconnect Switch

This product is suitable for passenger cars, trucks, tractors, professional racing cars, and now it has been applied to many ordinary RVs abroad. At present, this kind of modification combination switch is used in many coastal cities in China, and the installation is simple.

Specification

Product Name	Boat Marine RV Battery Switch
Switch Type	Single Circuit ON-OFF
Color	Red
Switch Positions	2
Maximum Voltage	32V DC
Continuous Rating	300A
Intermittent Rating	500A (5 min)
Starting Rating 30 sec	900A
Stud Size	3/8"
Battery Inputs	1
Mounting Holes	Accept #10 Screw
Stud Material	Tinned Copper
Terminal Stud Size	3/8" - 16 (M10)
Cable Clearance For 4/0 AWG Cables	1.12in (28.45 mm)
Cable Size to Meet Ratings	4/0 AWG (120mm²)
Stud Torque	120 in-lb (13.56 Nm)
Switching Rating	25A
Weight	0.65lb (0.29 kg)

Features

Switches a single battery to a single load group

•Ignition protected—safe for installation aboard gasoline powered boats

•Case design allows surface, front panel, or rear panel mounting

•Isolating cover with snap-on sections protects rear contacts

Function of 4 Position Cut Off 32V 48V DC Marine Boat Yacht RV Battery Isolator Switch Disconnect Switch

Prevent leakage, protect the power supply, disconnect the battery safely

Application of 4 Position Cut Off 32V 48V DC Marine Boat Yacht RV Battery Isolator Switch Disconnect Switch

The product has a wide range of uses and can be used as the on/off key for various electrical equipment added inside and outside the car (such as: strobe lights, chassis lights, fog lights, dome lights. Instantaneous power failure, etc.)
