| Price | Negotiable |
| MOQ | 3 pieces |
| Delivery Time | 3-8 Working Days |
| Brand | AIRSUSTECH |
| Place of Origin | Guangzhou, China |
| Certification | ISO/TS16949:2009 |
| Model Number | 2B7070 |
| Packaging Details | Strong Carton Box or as Customers Requirement |
| Payment Terms | T/T, Western Union,Paypal or Others |
| Supply Ability | 1000pcs/week |
| Condition | 100% Brand-new | Place of Origin | Guangzhou, China |
| Warranty | 12 Months | Size | 16*16*16 CM |
| Packaging Details | Strong Carton Box or as Customers Requirement | Color | Black |
| Material | Rubber+metal | Model Number | 2B7070 |
| Supply Ability | 1000pcs/week | Oe no. | W01-358-7025 |
| Certification | ISO/TS16949:2009 | Brand Name | AIRSUSTECH |
| Payment Terms | T/T, Western Union,Paypal or Others | Type | air Suspension Spring |
| Packing | Neutral box | Delivery Time | 3-8 Working Days |
| Minimum Order Quantity | 3 pieces | Shock absorber type | Gas-Filled |
| Application | Air spring |
W01-358-7025 Firestone Air Bags Maximum Diameter 6.5" Double Corrugated Spring
AIRSUSTECH 2B7070 Cross OEM Original Equipment Manufacturer:
| AIRSUSTECH Part Number:2B7070 | |
| Continental :FD 70-13 | Contitech Part Number: FD70-13 CI G1/4 |
| Contitech :FD 70-13 | Contitech Part Number: FD70 13 G1/4 |
| Continental :FD70-13 | Contitech Part Number: FD70 13 CI G1/4 |
| Contitech :FD70-13 | Contitech Part Number: FD 70 13 G1/4 |
| Continental Part Number: FD70-13 CI G1/4 | Contitech Part Number: FD7013 G1/4 |
| Continental Part Number: FD70 13 G1/4 | Contitech Part Number: FD7013 CI G1/4 |
| Continental Part Number: FD70 13 CI G1/4 | Continental Part Number: FD7013 G1/4 |
| Continental Part Number: FD 70 13 G1/4 | Continental Part Number: FD7013 CI G1/4 |
| Firestone Part Number: W013587025, | Firestone Part Number: WO13587025, |
| Firestone Part Number: W01-358-7025, | Firestone Part Number: WO1-358-7025 |
| Firestone Part Number: W01 358 7025, | Firestone Part Number: WO1 358 7025, |
One pc of AIRSUSTECH 2B7070 Package size and weight:
| Net Weight | Gross Weight |
Length (cm) |
Width (cm) |
Height (cm) |
Measurememt (cbm) |
| 1.6 | 2.0 | 16 | 16 | 16 | 0.01 |
| AIRSUSTECH 2B7070 Technical Parameters | |
| Top Cover Plate Diameter | 105 mm |
| Bottom Cover Plate Diameter | 105 mm |
| Screw Center Distance | 44.5 mm |
| Distance Gas Hole Between Nut | 22.25mm |
| Gas Hole | G1/4 |
| Screw (Nut) Tooth | 2pcsXm8 |
| Rubber Bellows Diameter | Natural Φ146 mm |
| The Height | Natural 180mm |
Compression
height
2.83"
Maximum
unfolded
height
7.87"
The
maximum
diameter
6.5"
maximum
inflation
pressure
120
psi
Maximum
stroke
5.04"
Air
intake
type
empire
air
inlet
1/4"
series
C
lowest
temperature
-76°F
maximum
temperature
158°F
Bellows
type
double
roundabout
weight
3.31
lbs.
AIRSUSTECH 2B7070 Replaces W01-358-7025 Firestone Air Bags product description:
The air spring shock absorber AIRSUSTECH 2B7070 Replaces W01-358-7025 Firestone Air Bags can only push the bellows towards the workpiece, otherwise it must be equipped with a stroke limiter at the end of the stroke, otherwise the bellows will be overloaded
• In order to press the air spring shock absorber AIRSUSTECH 2B7070 Replaces W01-358-7025 Firestone Air Bags to the minimum height, a restoring force is required. Usually, this is achieved by applying a load
• The entire bearing surface of the upper and lower plates of the air spring shock absorber AIRSUSTECH 2B7070 Replaces W01-358-7025 Firestone Air Bags must be used to absorb the force
• Before disassembling the air spring shock absorber AIRSUSTECH 2B7070 Replaces W01-358-7025 Firestone Air Bags, the internal air must be released to prevent accidents and personal injury.
• During operation, the rubber air spring shock absorber AIRSUSTECH 2B7070 Replaces W01-358-7025 Firestone Air Bags shall not be in contact with other parts
