| Price | Negotiable |
| MOQ | 3 pieces |
| Delivery Time | 3-8 Working Days |
| Brand | AIRSUSTECH |
| Place of Origin | Guangzhou, China |
| Certification | ISO/TS16949, ISO9001 |
| Model Number | G3001 |
| Packaging Details | Strong Carton Box or as Customers Requirement |
| Payment Terms | T/T, Western Union,Paypal or Others |
| Supply Ability | 1000pcs/week |
| Origin | Guangzhou, China | Packaging Details | Strong Carton Box or as Customers Requirement |
| HS Code | 8708809000 | Port | Huangpu, China |
| Trademark | Neutral | Supply Ability | 1000pcs/week |
| Bottom Plate Hole/Stud | 5/8-11unc | Air Inlet | 1/8-27 nptf |
| Plate Diameter | 74.5 mm | Transport Package | Cartons |
| Minimum Order Quantity | 3 pieces | Place of Origin | Guangzhou, China |
| Warranty | One Year | Position | Middle |
| Specification | 12*9*9 cm | Material | Rubber and steel |
| Model Number | G3001 | Certification | ISO/TS16949, ISO9001 |
| Brand Name | AIRSUSTECH | Payment Terms | T/T, Western Union,Paypal or Others |
| Pressure Ability | 0.2-0.8 M PA | Type | Air isolator Spring |
| N.W. | 0.26 Kg | Delivery Time | 3-8 Working Days |
| Top Plate Hole/Stud | 5/16-18unc | OEM | Yes |
| Top Plate Dia | 74.5 mm | Bottom Plate Dia | 61.2 mm |
Why use AIRSUSTECH G3000 Replaces Firestone W02-358-3001 actuator (instead of air or hydraulic cylinder) for vibration isolation?
low
cost
Generally,
the
initial
cost
is
half
or
less
of
a
conventional
pneumatic
cylinder
or
hydraulic
cylinder
with
the
same
force.
The
initial
cost
advantage
is
the
larger
size.
Wide
range
The
diameter
of
AIRSUSTECH
G3000
Replaces
Firestone
W02-358-3001
actuator
ranges
from
2.2
inches
to
37
inches.
The
strength
capacity
is
100,000
pounds.
The
stroke
can
reach
14
inches.
Durable
AIRSUSTECH
G3000
Replaces
Firestone
W02-358-3001
actuator
is
a
further
application
of
Firestone’s
proven
AIRSUSTECH
G3000
Replaces
Firestone
W02-358-3001
spring
for
Suspension
of
trucks
and
buses.
Long
life
and
durability
needed
for
millions
of
miles
The
use
of
heavy-duty
suspensions
under
adverse
environmental
conditions
is
also
an
important
factor
in
mechanical
design.
No maintenance or lubrication required
No
inner
rod
or
piston
AIRSUSTECH
G3000
Replaces
Firestone
W02-358-3001
stroke
actuators
do
not
have
traditional
internal
rods,
pistons
or
sliding
seals
Gas
cylinder.
This
allows
the
stroke
actuator
to
be
designed
for
dirty
or
oily
applications.
Coarse
sand
will
destroy
the
seal
on
a
conventional
cylinder.
No
friction,
immediate
response
Since
the
actuator
does
not
have
a
sliding
seal,
it
will
not
look
like
Angle
ability
Airstrikes
have
a
unique
ability
to
make
strokes
through
arcs
without
a
U-shaped
clip.
Angular
movement
up
to
30
degrees
AIRSUSTECH G3000 Cross others OEM
Manufacturer :AIRSUSTECH
Manufacturer Part Number :AIRSUSTECH G3001
Firestone Bellows Number :1M1A
Firestone Bellows Number :W02-358-3001
Firestone Part Number :W02-358-3001
Firestone Part Number :W02 358 3001
Firestone Part Number :W023583001
AIRSUSTECH G3001 Technical Parameters
Nut / Blind Nut
Top Cover Plate Screw (Nut) Tooth : 1pcX5/16-18unc
Screw Center Distance of Top Cover Plate : in the middle
Bottom Cover Plate Screw (Nut) Tooth : 1pcX5/8-11unc
Screw Center Distance of Bottom Cover Plate : in the middle
Gas Hole / Air inlet / Air Fitting
Gas Hole / Air inlet : 1/8 N P.T.F. / 1/4NPTF
Cover Plate
Top Cover Plate Diameter: 74.5 mm
Bottom Cover Plate Diameter: 61.2 mm
Rubber Bellows
Rubber Bellows MAX Diameter: 91.5 mm
Rubber Bellows Natural Diameter :80 mm
The Working Stroke : MAX 91 mm to MIN 38 mm
Maximum Height :91 mm
Minimum Height :38 mm
Compression Height : 53 mm
Bumper block / Buffer block
Without Bumper Block
Girdle Hoop / Girdle Ring
With Girdle Hoop :no Pieces of Girdle Hoop
