Price	Negotiable
MOQ	3 pieces
Delivery Time	3-8 Working Days
Brand	AIRSUSTECH
Place of Origin	Guangzhou, China
Certification	ISO/TS16949, ISO9001
Model Number	2B2200
Packaging Details	Strong Carton Box or as Customers Requirement
Payment Terms	T/T, Western Union,Paypal or Others
Supply Ability	1000pcs/week

Product Details

Origin	China	Packaging Details	Strong Carton Box or as Customers Requirement
HS Code	8708809000	Port	Huangpu, China
Trademark	Neutral	Supply Ability	1000pcs/week
Bottom Plate Hole/Stud	3/8 NPT	Air Inlet	1/4 NPT
Transport Package	Cartons	Minimum Order Quantity	3 pieces
Place of Origin	Guangzhou, China	Warranty	One Year
Position	Front and Rear	Specification	242424 cm
Material	Rubber and Iron	Model Number	2B2200
Certification	ISO/TS16949, ISO9001	Payment Terms	T/T, Western Union,Paypal or Others
Brand Name	AIRSUSTECH	Pressure Ability	0.2-0.8 M PA
Type	Suspension Spring	N.W.	1.5 Kg
Model NO.	2B2200	Delivery Time	3-8 Working Days
Top Plate Hole/Stud	3/8 NPT	OEM	Yes
Top Plate Dia	97 mm	Bottom Plate Dia	97 mm

AIRSUSTECH 2B2200 Specification:

Nut/ Blind Nut
Top cover screw (nut) teeth: 2 x 3 / 8-16UNC
Top cover screw center distance: 44.5 mm

Bottom cover screw (nut) teeth: 1 X 3 / 8-16UNC
Bottom cover screw center distance: middle

air hole / air inlet / air connector
Air vent / air inlet: 1 / 4 NPT
Center distance between air inlet and nut: 22 mm

cover
Top cover diameter (width): 97 mm
Bottom cover diameter (width): 97 mm

Rubber bellows
Rubber bellows natural diameter: 100 mm
Rubber bellows MAX diameter: 120 mm
Design height: 124mm
Bellows no.:2200

bumper block / buffer block
No Bumper Block

Operating Temperature: 57Cº to -54Cº

Twisted waist/waist ring
Belt loop: two belt loops

Air spring volume saves space compared to other springs
Roller protects air springs from wear and increases load capacity
No drilling required - Most kits use existing holes in the vehicle frame for bolt mounting
Easy to install, ordinary car repairers can operate
All kits are compatible with most 5-wheel and gooseneck hooks

2b2200 Air Suspension Springs Design Height 180 mm Double Convoluted Air Bag for Modification of Japanese Cars
