| Price | Negotiable |
| MOQ | 1 pieces |
| Delivery Time | 3-8 Working Days |
| Brand | AIRSUSTECH |
| Place of Origin | Guangzhou, China |
| Certification | ISO/TS16949:2009 |
| Model Number | 1H150076 |
| Packaging Details | Strong Carton Box or as Customers Requirement |
| Payment Terms | T/T,Western Union,Paypal or Others,L/C,D/A,D/P,MoneyGram |
| Supply Ability | 1000pcs/week |
| Place of Origin | Guangzhou, China | Max. Diameter | 95 MM |
| Packaging Details | Strong Carton Box or as Customers Requirement | Compressed Height | 45 MM |
| Static Height | 76 MM | Material | Rubber+Steel |
| Model Number | 1H150076 | Trademark | AIRSUSTECH |
| Supply Ability | 1000pcs/week | Certification | ISO/TS16949:2009 |
| Brand Name | AIRSUSTECH | Payment Terms | T/T,Western Union,Paypal or Others,L/C,D/A,D/P,MoneyGram |
| Ships To | Worldwide | Price | Negotiable |
| Delivery Time | 3-8 Working Days | Minimum Order Quantity | 1 pieces |
| Working Temperature | -40℃+70℃ |
| Attribute | Value |
|---|---|
| Trademark | AIRSUSTECH |
| Model Number | 1H150076 |
| Compressed Height | 45 MM |
| Max. Diameter | 95 MM |
| Static Height | 76 MM |
| Material | Rubber+Steel |
| Ships To | Worldwide |
| Working Temperature | -40℃ to +70℃ |
| Load (kg) | Installation Height (mm) | Inflation Pressure | 0.2 MPa | 0.3 MPa | 0.4 MPa | 0.5 MPa | 0.6 MPa | 0.7 MPa | 0.8 MPa | Volume at 0.7MPa (dm3) |
|---|---|---|---|---|---|---|---|---|---|---|
| 45 | 436 | 579 | 718 | 860 | 1008 | 1155 | 1301 | 0.37 | ||
| 55 | 299 | 428 | 570 | 700 | 830 | 963 | 1088 | 0.46 | ||
| 65 | 226 | 335 | 451 | 565 | 670 | 782 | 906 | 0.57 | ||
| 76 | 164 | 258 | 344 | 435 | 526 | 621 | 720 | 0.67 | ||
| 85 | 122 | 190 | 254 | 330 | 399 | 475 | 544 | 0.75 | ||
| 95 | 58 | 94 | 133 | 174 | 220 | 263 | 308 | 0.87 |
| Vertical Stiffness (Kg/cm) | 107 | 150 | 187 | 231 | 265 | 303 | 319 |
|---|---|---|---|---|---|---|---|
| Natural Frequency (Hz) | 4.05 | 3.82 | 3.69 | 3.65 | 3.55 | 3.5 | 3.33 |
| Natural Frequency (cpm) | 243 | 229 | 221 | 219 | 213 | 210 | 199 |
H-Type rubber air springs deliver exceptional vibration isolation across both high and low frequencies, effectively protecting sensitive equipment from harmful oscillations. The flexible air chamber design absorbs and dissipates mechanical vibrations while reducing operational noise levels by up to 15dB compared to conventional spring systems.
These air springs feature adjustable air pressure control, enabling precise tuning for varying load requirements. This adaptive capability makes them ideal for dynamic systems including HVAC units, industrial compressors, and automated platforms where load conditions frequently change.
The unique movable flange design simplifies maintenance and repair operations. Users can effortlessly replace just the rubber airbag component when needed, significantly reducing downtime and repair costs compared to traditional suspension systems.
Constructed from high-performance neoprene rubber compounds, H-Type air springs withstand thousands of compression cycles in demanding industrial environments. The wear-resistant materials maintain consistent performance characteristics even under continuous heavy loading conditions.
The frictionless air cushion operation eliminates metal-to-metal contact points, removing the need for regular lubrication. This maintenance-free design translates to lower operating costs and increased system reliability over extended service periods.
Despite their compact cylindrical form factor, these air springs deliver impressive load-bearing capacity. The space-saving design allows for easy integration into equipment with limited installation space while still providing superior vibration isolation performance.
