W01-M58-6155 Firestone Pneumatic Rubber Bellow Full Stroke 63MM Single Air Spring

Price	Negotiable
MOQ	1
Delivery Time	5-8 Working Days
Brand	AIRSUSTECH
Place of Origin	Guangzhou,China
Certification	ISO/TS16949:2009
Model Number	1B7070
Packaging Details	Strong Carton Box or as Customers Requirement
Payment Terms	T/T, Western Union, Paypal or Others
Supply Ability	1000PCS/Week

Product Details

Product Specification

Place of Origin	Guangzhou,China	Bellows Type	Single Convoluted
Part Number	1B7070	Contitech	FS 70-7
Festo	EB-165-65	Packaging Details	Strong Carton Box or as Customers Requirement
Port Size	1/4 BSP	Model Number	1B7070
Supply Ability	1000PCS/Week	Certification	ISO/TS16949:2009
Brand Name	AIRSUSTECH	Payment Terms	T/T, Western Union, Paypal or Others
Pressure Ability	0 Bar - 8 Bar	Price	Negotiable
Delivery Time	5-8 Working Days	Max. Bellow Diameter	165 MM
Minimum Order Quantity	1	Supplier	AIRSUSTECH

Product Description

W01-M58-6155 Firestone Pneumatic Rubber Bellow Full Stroke 63MM Single Air Spring

Air Spring Introduction

The AIRSUSTECH NO. 1B7070 Single Convoluted Industrial Air Spring is a compatible replacement for Contitech FS 70-7, Firestone W01-M58-6155, Phoenix SP 1B 05, Bosch 8224 19002, Festo EB-165-65, and Weforma WBE 200-E1. The 1B7070 air spring shares the same technical parameters as Firestone W01-M58-6155. Additionally, we provide a 12-month warranty for our air rubber bellows. Our air springs adhere to international standards ISO/TS16949:2009, ensuring reliable quality and performance.

1B7070 Air Actuator Specifications

Diameter of the Top Cover Plate: 114 mm

Center-to-Center Distance of Screws on the Top Cover Plate: 44 mm

Diameter of the Bottom Cover Plate: 114 mm

Center-to-Center Distance of Screws on the Bottom Cover Plate: 44 mm

Screw (Nut) Thread Count for the Top Cover Plate: 2×M8

Screw (Nut) Thread Count for the Bottom Cover Plate: 2×M8

Air Inlet: 1/4 BSP

Maximum Diameter of the Rubber Bellow: 165 mm

Maximum Height: 114 mm

Minimum Height: 51 mm

Part Interchanges

Firestone Air Spring: W01-M58-6155

Firestone Air Spring: W01M586155

Firestone Air Spring: W01 M58 6155

Contitech Air Spring: FS 70-7

Contitech Air Spring: FS70-7

Contitech Air Spring: FS707
Phoenix Air Spring: SP 1B 05

Phoenix Air Spring: SP 1B05

Phoenix Air Spring: SP1B05
Bosch Air Spring: 8224 19002

Bosch Air Spring: 822419002
Festo Air Spring: EB-165-65

Festo Air Spring: EB16565

Festo Air Spring: EB 165 65
Weforma Air Spring: WBE 200-E1

Weforma Air Spring: WBE200-E1

Weforma Air Spring: WBE200E1

Support and Services

Our Suspension Air Springs come with comprehensive technical support and services, including:

Expert Troubleshooting: Professional assistance to diagnose and resolve technical issues effectively.
Installation and Maintenance Guidance: Detailed instructions to ensure the proper use and upkeep of our products.
Comprehensive Documentation: Access to user manuals and technical specifications for better understanding and operation.
Product Training and Education: Tailored training programs for customers and service technicians to ensure optimal product use.
Warranty and Repair Services: Coverage includes replacement parts and exchange programs for enhanced peace of mind.
Customer Support: Immediate assistance for urgent technical issues or service needs.
