622Mb/s SFP Transceiver singlemode dual fiber 80km 1550nm LC DDM

Price	Negotiable
MOQ	1 piece
Delivery Time	Within 1-3 work days
Brand	NuFiber
Place of Origin	China
Certification	CE FCC Rohs
Model Number	622M-LX80-SM1550
Packaging Details	10pcs/plastic bag,500pcs/carton, carton size: 455328280mm
Payment Terms	L/C, T/T, Western Union,Credit Card
Supply Ability	100,000 pcs per month

Product Details

Product Specification

Connector	LC	Place of Origin	China
Warranty	1 year	Packaging Details	10pcs/plastic bag,500pcs/carton, carton size: 455328280mm
Product Name	622Mbps SFP Transceiver	Model Number	622M-LX80-SM1550
DDM	Support	Fiber Type	Duplex LC Singlemode
Compatible	Cisco Huawei HP Juniper etc...	Supply Ability	100,000 pcs per month
Certification	CE FCC Rohs	Wavelength	1550nm
Power Supply	3.3V	Brand Name	NuFiber
Payment Terms	L/C, T/T, Western Union,Credit Card	Delivery Time	Within 1-3 work days
Minimum Order Quantity	1 piece	Working Temperature	0-70℃
Manufacturer	Yes	Distance	80KM

Product Description

622Mb/s SFP Transceiver singlemode dual fiber 80km 1550nm LC DDM

Description

Nufiber’s 622M-LX80-SM1550 Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1550nm DFB laser, up to 25dB link budge ensure this module SONET OC-12/SDH STM-4 80Km application.

Features

Up to 622Mb/s Data Links
Hot-Pluggable
Duplex LC connector
Up to 80km on 9/125μm SMF
1550nm DFB laser transmitter
Single +3.3V Power Supply
Monitoring Interface Compliant with SFF-8472
Maximum Power <1W
Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available
RoHS compliant and Lead Free

Applications

►SONET OC-12/SDH STM-4

►Fast Ethernet

►Other Optical Links

Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)

Parameter	Symbol	Min.	Typical	Max.	Unit	Note
Transmitter Section:
Center Wavelength	λ_c	1530	1550	1570	nm
Spectral Width	σ			1	nm
Optical Output Power	P_out	-3		+2	dBm	1
Optical Rise/Fall Time	t_r / t_f			300	ps	2
Extinction Ratio	ER	10			dB
Generated Jitter (peak to peak)	J_TXp-p			0.07	UI	3
Generated Jitter (rms)	J_TXrms			0.07	UI	3
Eye Mask for Optical Output	Compliant with G.957(class 1 laser safety)
Receiver Section:
Optical Input Wavelength	λ_c	1260		1600	nm
Receiver Overload	P_ol	-8			dBm	4
RX Sensitivity	Sen			-28	dBm	4
RX_LOS Assert	LOS _A	-45			dBm
RX_LOS De-assert	LOS _D			-29	dBm
RX_LOS Hysteresis	LOS _H	0.5			dB
General Specifications:
Data Rate	BR		622		Mb/s
Bit Error Rate	BER			10^-12
Max. Supported Link Length on 9/125μm SMF@622Mb/s	L_MAX		80		km
Total System Budget	LB	25			dB

Ordering Information

Dual Fiber SFP Transceiver
Part Number	Product Description
155Mbp/s SFP Transceiver
FE-SX-MM850	155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C
FE-SX-MM1310	155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
FE-LX20-SM1310	155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
FE-LX40-SM1310	155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
FE-LX80-SM1550	155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
FE-LX120-SM1550	155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
1.25Gbps SFP Transceiver
GE-SX-MM850	1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C
GE-SX-MM1310	1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
GE-LX20-SM1310	1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
GE-LX40-SM1310	1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
GE-LX60-SM1550	1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C
GE-LX80-SM1550	1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
GE-LX120-SM1550	1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
10Gbps SFP Transceiver
SFP+-10GB-SR	10G SFP+ SR Multi mode dual fiber LC 850nm 300M
SFP+-10GB-LRM	10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M
SFP+-10GB-LR	10G SFP+ LR Single mode dual fiber LC 1310nm 20km
SFP+-10GB-ERM	10G SFP+ER Single mode dual fiber LC 1310nm 40km
SFP+-10GB-ER	10G SFP+ER Single mode dual fiber LC 1550nm 40km
SFP+-10GB-ZR	10G SFP+ZR Single mode dual fiber LC 1550nm 80km
SFP+10G40-CWDM	1470 ~1610nm CWDM SFP+ 40km
SFP+10G80-CWDM	1470~1570nm CWDM SFP+ 80km
SFP+10G80-CWDM	1590~1610nm CWDM SFP+ 80km
SFP+10G40-DWDM	DWDM SFP+ 40km
SFP+10G80-DWDM	DWDM SFP+ 80km
XFP Transceiver
XFP-10G-SR	10G XFP SR Multi mode dual fiber LC 850nm 300M
XFP-10G-LRM	10G XFP LRM Single mode dual fiber LC 1310nm 10kM
XFP-10G-LR	10G XFP LR Single mode dual fiber LC 1310nm 20km
XFP-10G-ER	10G XFP ER Single mode dual fiber LC 1550nm 40km
XFP-10G-ZR	10G XFP ZR Single mode dual fiber LC 1550nm 80km
CWDM DWDM Transceiver
XFP-CWDM-40xx	1470 ~1610nm CWDM XFP 40km
XFP-CWDM-80xx	1470~1570nm CWDM XFP 80km
XFP-CWDM-80xx	1590~1610nm CWDM XFP 80km
XFP-DWDM-40xx	DWDM XFP 40km
XFP-DWDM-80xx	DWDM XFP 80km
XFP-DWDM-100xx	DWDM XFP100km
