| Price | USD 500-1000 per Ton |
| MOQ | 1 Ton |
| Delivery Time | 5-15 working days |
| Brand | CH Refractories |
| Place of Origin | China |
| Certification | ISO |
| Model Number | AZS |
| Packaging Details | Pallet |
| Payment Terms | L/C, T/T |
| Supply Ability | 5000 Ton per month |
| Place of Origin | China | Packaging Details | Pallet |
| Color | White | Model Number | AZS |
| type | Factory | Supply Ability | 5000 Ton per month |
| Certification | ISO | Name | Glass Kiln Applied Fused Cast AZS Block |
| Brand Name | CH Refractories | Payment Terms | L/C, T/T |
| application | Glass kiln | Price | USD 500-1000 per Ton |
| Delivery Time | 5-15 working days | Minimum Order Quantity | 1 Ton |
Glass Kiln Fused Cast AZS Block For Glass Kiln Sell To Global
Glass Kiln Applied Fused Cast AZS Block
AZS-36# Brick is a standard zirconia fused zirconium corundum brick, which has the characteristics of high corrosion resistance and low pollution resistance of glass liquid, and the performance in these two aspects is balanced. The fused cast AZS brick is suitable for the parts in the glass furnace which are in direct contact with the glass liquid, such as the wall brick of the melting pool, the paving brick, the feeding port and so on.
AZS-41# brick is very high-grade zirconia fused zirconium corundum brick, it has very high corrosion resistance of glass liquid and outstanding low pollution to glass liquid. It is suitable for the parts with high corrosion resistance in glass kiln, such as full electric furnace, fluid hole, kiln, bubble brick, brick at the corner of feeding, etc.
Applications of Zirconia Corundum(AZS) Brick:
Widely be used for linings of furnace in glass industries.
| Items | Unit | Index | ||||
| AZS33-Y | AZS36-Y | AZS41-Y | ||||
| Chemical composition | Al2O3 | % | ≤50 | ≤42 | ≤40 | |
| ZrO2 | % | 32-36 | 35-40 | 40-44 | ||
| 1650 | SiO2 | % | ≤16 | ≤14 | ≤13 | |
| Na2O | % | ≤1.45 | ≤1.45 | ≤1.3 | ||
| Fe2O3+TiO2+CaO+MgO+Na2O+K2O | % | ≤2 | ≤2 | ≤2 | ||
| Fe2O3+TiO2 | % | ≤0.3 | ≤0.3 | ≤0.3 | ||
| Bulk density | g/cm3 | ≥3.75 | ≥3.8 | ≥3.95 | ||
| Apparent porosity | % | ≤1.5 | ≤1 | ≤1 | ||
| Static anti-corrosion rate of glass liquid(ordinary soda-lime glass, 1500℃*36h) | Mm/24h | ≤1.5 | ≤1.4 | ≤1.3 | ||
| Initial exudation temperature of glass phase | ℃ | ≥1400 | ≥1400 | ≥1400 | ||
| Bubble release proportion (ordinary soda-lime glass, 1300℃*10h) | % | ≤2 | ≤1.5 | ≤1 | ||
| Glass phase seepage discharge(1500℃*4h) | % | ≤2 | ≤3 | ≤3 | ||
| Working temperature | ℃ | ≥1650 | ≥1650 | ≥1650 | ||
Advantages of CH series Glass Kiln Applied Fused Cast AZS Block:
Erosion resistance. Ultra low apparent porosity
High strength and high compression resistance
Thermal shock resistance and erosion resistance
Performance in high temperature, good thermal conductivity
Free sampleFree construction guidance free 3D design
Customerize mould according to different size requirements for free
Caihua refractory company manufactured azs bricks with very competitive price comparing with other suppliers in China.
