| Price | 200-500USD/T |
| MOQ | 1 Ton |
| Delivery Time | 5-15 working days |
| Brand | CH Refractories |
| Place of Origin | China |
| Certification | ISO |
| Model Number | NG0.6 NG0.8 NG1.0 |
| Packaging Details | Paper box on Pallet |
| Payment Terms | T/T, L/C |
| Supply Ability | 5000 Ton per month |
| Usage | Fire resistance place | Place of Origin | China |
| Al2o3 content (%) | ≥48% | Packaging Details | Paper box on Pallet |
| Color | Yellow | Model Number | NG0.6 NG0.8 NG1.0 |
| Supply Ability | 5000 Ton per month | Certification | ISO |
| Name | Insulating Refractory Brick High Temperature Insulation Brick | Brand Name | CH Refractories |
| Payment Terms | T/T, L/C | Thickness | common or customization |
| Type | Insulation brick | Price | 200-500USD/T |
| Delivery Time | 5-15 working days | Minimum Order Quantity | 1 Ton |
Insulating Refractory Brick High Temperature Insulation Brick made by CH Refractory has advantages with small bulk density, high cold crushing strength, and high refractoriness under load, small dimension tolerance and good thermal shock resistance. Lowest and most stable thermal conductivity in various insulating refractory bricks. It can reduce the total weight of furnace body and the thickness of furnace wall effectively, improve heat efficiency, lower energy consumption, improve work conditions and production efficiency, and considerable economic benefit can be obtained.
Just please inform us your required bricks working temperature, we can provide you the most economical suggestions to you.
Physical and chemical index of Fire Refractory Insulating Brick
| Brands | Clay Insulation Brick | |||
| / | CH-NG-0.5 | CH-NG-0.6 | CH-NG-0.8 | CH-NG-1.0 |
| BD g/cm3 | 0.5 | 0.6 | 0.8 | 1 |
| CCS/Mpa ≥ | 1.5 | 2 | 2.5 | 3.4 |
| The reheating line changes by no more than 2% of the test temperature/℃≤ | 1250 | 1300 | 1350 | 1350 |
| Thermal conductivity average temperature 350±25℃(W/m.k) | 0.18 | 0.25 | 0.35 | 0.5 |
| 0.1MpaRefractoriness under load (RUL)/ | 1160 | 1250 | 1280 | 1300 |
| Fe2O3% | 2.5 | 2.5 | 2 | 2 |
| Maximum use temperature/℃ | 1150 | 1200 | 1280 | 1300 |
| Brands | CH-LG-0.6 | CH-LG-0.8 | CH-LG-1.0 |
| BD g/cm3 | 0.6 | 0.8 | 1 |
| CCS /Mpa ≥ | 1.96 | 2.94 | 4 |
| The reheating line changes by no more than 2% of the test temperature /℃≤ | 1350 | 1400 | 1450 |
| Thermal conductivity average temperature 350±25℃(W/m.k) | 0.25 | 0.32 | 0.45 |
| 0.1MpaRUL/ | 1300 | 1350 | 1380 |
| Al2O3 /%≥ | 48 | 48 | 48 |
| Fe2O3 /% | 1.8 | 1.6 | 1.5 |
| Maximum use temperature /℃ | 1300 | 1350 | 1380 |
Applications
of
Fire
Refractory
Insulating
Brick:
Thermal
equipment
and
furnace
lining
Insulation
of
masonry
industrial
furnaces
