| Price | Negotiable |
| MOQ | 50 |
| Delivery Time | 45 days |
| Brand | Huaye |
| Place of Origin | China |
| Certification | ISO14000 |
| Packaging Details | standard export packing |
| Payment Terms | L/C, T/T |
| Supply Ability | 10000 |
| Top surface | 10 micron polyester + 5 micron primer | Place of Origin | China |
| Packaging Details | standard export packing | Coil ID | 508mm/610mm |
| Coil Weight | max. 8 MT | Supply Ability | 10000 |
| Certification | ISO14000 | Brand Name | Huaye |
| Payment Terms | L/C, T/T | Thickness | 0.18-1.20mm |
| Back surface | 5 - 7 micron | Commodity | Prepainted Color Steel Coils / coil |
| Color: | According to RAL Card or Clients' requests | Delivery Time | 45 days |
| Minimum Order Quantity | 50 |
15 - 20 micron polyester + 5 micron primer LFQ AZ Prepainted Color Steel Coils / coil
As per JIS G3322 CGLCC, ASTM A755, GB/T 12754, EN 10169 DX51D+AZ
commercial quality or Lock forming quality (LFQ), AZ coating:50 g/m2 to 180 g/m2
Top surface : 15 - 20 micron polyester + 5 micron primer , Back surface: 5 - 7 micron
or 7-8 micron polyester + 5 micron primer
Color: According to RAL Card or Clients' requests
Coil Weight max. 13 MT
Coil ID:508mm/610mm
With or without protective film on the top side
Categories of paint: polyester/silicon modified polyester (SMP)/PVDF
Thickness: 0.18-1.20mm
Width: 700-1250mm
Minimum order: 50MT per size
| Product Name | 15 - 20 micron polyester + 5 micron primer LFQ AZ Prepainted Color Steel Coils / coil |
| Products | GI/GL PPGI/PPGL Plain Sheet Corrugated Steel Sheet |
| Grade | SGCC,SGLCC, CGCC, SPCC, ST01Z, DX51D, A653 |
| Standard | JIS G3302 / JIS G3312 /JIS G3321/ ASTM A653M / A924M 1998 |
| Origin | China(Mainland) |
| Raw material | SGCC, SPCC, DX51D, SGCH,ASTM A653,ASTM A792 |
| Certificate | ISO9001.ISO14001.OHSAS18001,SGS |
| Surface Treatment | Chromated, Skin Pass, Dry,Unoild, Etc |
| Thickness | 0.18mm-1.2mm |
| Width | 700mm-1250mm |
| Tolerance | Thickness+/-0.01mm Width +/-2mm |
| Zinc coating | 40-275g /m2 |
| Color options | RAL Color System or as per buyer’s color sample. |
| Coil weight | Max 13MT |
| Application | Industrial and civil construction, steel structure buildings and producing roofing sheets |
| Spangle | Big / Small / Minimum/No spangle |
| Hardness | Soft & Full Hard or As Per Customer Request |
| Packing |
INNER 3MM STEEL SLEEVES ,WRAPPED BY WATERPROOF PAPER, THEN STEEL SHEETS OUTSIDE. STRAPPED 4 PLACE HORIZONTALLY AND 3 PLACES VERTICALLY. |
| Payment term | T/T OR L/C |
| Price | FOB/CFR/CNF/CIF |
| Delivery time | Around 45 days after T/T payment or L/C is received |
Quality Control
