| Price | USD500-800/MT |
| MOQ | 50mt |
| Delivery Time | 45days |
| Brand | RAYMOND |
| Place of Origin | China |
| Certification | ISO14000 |
| Packaging Details | standard export packing |
| Payment Terms | L/C, T/T, Western Union, MoneyGram, D/A, D/P |
| Supply Ability | 10000MT/ month |
| Zinc Coating | 100g/㎡ | Place of Origin | China |
| Packaging Details | standard export packing | Color | RAL 2003 |
| Standard | ASTM,GB | Supply Ability | 10000MT/ month |
| Certification | ISO14000 | Brand Name | RAYMOND |
| Payment Terms | L/C, T/T, Western Union, MoneyGram, D/A, D/P | Thickness | 0.62mm |
| Type | Steel Coil | Commodity | Pre-painted steel coil |
| Price | USD500-800/MT | Delivery Time | 45days |
| Minimum Order Quantity | 50mt | Application | Flange Plate |
| Width | 1000mm |
JIS G3141 SOFT QUALITY G550 HIGH GLOSSY BRICK PATTERN COLOR STEEL PREPAINTED PPGI COLOR COATED COIL
PPGI
(PPGL)
Features:
| Item name | Prepainted galvanized steel coils on sale | ||
| Grade | DX51D+Z | S250GD+Z | |
| SGCC | DX52D+Z | S280GD+Z | |
| SGCD | DX53D+Z | S350GD+Z | |
| SGCE | DX54D+Z | S550GD+Z | |
| DX56D+Z | |||
| Thickness | 0.12 ~ 3.00 mm (cold rolled) | ||
| 1.20 ~ 4.60 mm (Hot-rolled ) | |||
| Width | 10 - 600 mm (strip) | ||
| 600 - 1250 mm (coil) | |||
| Tolerance | Thickness: ±0.01 mm | ||
| Width: ±2 mm | |||
| Coil ID | 508 mm - 610 mm | ||
| Coil weight | 3 - 8 ton or as client requirement. | ||
| Zinc coating | 30g - 275g / m2 | ||
| Spangle | Big spangle,Regular spangle,Mini spangle,Zero spangle | ||
| Surface treatment | Oil,Passivation, Chromated, Skin-passed, Anti-finger Print | ||
| HS code | code 72104900 | ||
| Application | Widely used in road, railway, civil construction, water conservancy construction; all kinds of machinery, electrical appliances, window protection and aquaculture, etc. | ||
| Package | Standard export package (Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet) | ||
| Delivery time | Within 15 workdays after deposit received | ||
| Remarks |
Insurance
per
to
Contract
terms; MTC will be handed on with shipping documents; We accept the third party certificatation test. |
||
MTC of pre painted galvanized steel coil
| COMMODITY: | PRE-PAINTED ZINC STEEL SHEET | Contract NO. | HYEXP2010-07-10A | Date: | SEPTEMBER-17-2010 | ||||||||||||||||
| Steel Grade: | ACC JIS G3312, SOFT MATT | Condition of Supply | PRE-PAINTED ZINC STEEL SHEET |
Certificate NO. |
100710A | ||||||||||||||||
| No. | Heat No. | Size(mm) | Zinc Coating: | Color side A | Coat property | Steel property | |||||||||||||||
| Pain thick (μm) | T-Bend (T) | Impact (J) | Gloss (GU) | Pencil hard | YS. Re Mpa | UTS. Rm Mpa | EL. A % | ||||||||||||||
| 1 | 0710225 | 0.30X800 MM RAL5012 | Z-60 | RAL 5012/25 microns | 25 | 3 | 9 | 50 | 3H | 360 | 380 | 35 | |||||||||
| 2 | 0710296 | 0.30X800 MM RAL8004 | Z-60 | RAL 8004/25 microns | 25 | 3 | 9 | 55 | 3H | 365 | 373 | 37 | |||||||||
| 3 | 0710246 | 0.25X800 MM RAL5012 | Z-60 | RAL 5012/25 microns | 25 | 3 | 9 | 50 | 3H | 358 | 375 | 36 | |||||||||
| 4 | 0710288 | 0.25X800 MM RAL8004 | Z-60 | RAL 8004/25 microns | 25 | 3 | 9 | 55 | 3H | 355 | 368 | 36 | |||||||||
Product Picture
