| Price | $200-6000/piece |
| MOQ | 1piece |
| Delivery Time | 15days |
| Brand | XINCHENG |
| Place of Origin | Qingdao |
| Certification | CCS,ABS,BV,LR,CCS BV GL |
| Model Number | 1.8*15m |
| Packaging Details | deflated by tray |
| Payment Terms | Western Union, MoneyGram, T/T, L/C |
| Supply Ability | 150PCS per month |
| Place of Origin | Qingdao | Warranty | 2 Years |
| Size | Customized Size | Packaging Details | deflated by tray |
| Color | blank | Material | Natural Rubber |
| Model Number | 1.8*15m | Supply Ability | 150PCS per month |
| Certification | CCS,ABS,BV,LR,CCS BV GL | Brand Name | XINCHENG |
| Payment Terms | Western Union, MoneyGram, T/T, L/C | Working pressure | 0.05MPa-0.17MPa |
| Price | $200-6000/piece | Delivery Time | 15days |
| Minimum Order Quantity | 1piece | Long | 8--24M |
| Lifespan | 8~10 Years |
ISO 14409 Rubber Airbag , Natural Rubber Made Of Air Lifting Bags
Marine airbags are widely used for ship launching, heavy transportation and marine salvage nowadays. Marine airbags are often called ship launching airbags that indicate the most popular application of these heavy duty airbags is for ship launching. It is estimated that more than 80 percent new built ships who’s DWT below 60,000 are launched by marine airbags.
1. usually produce and supply airbags in size of following as per customer’s launching requirement:
Diameter: 0.8m, 1.0m, 1.2m, 1.5m, 1.8m, 2.0m, 2.5m
Effective length: 5m-24m
Layer: 4-10 layers
| Dia | Effective Length | Layers with cord | Working Pressure | Bearing Capacity | |
| Lifting Height | Tons/Airbag | ||||
| 1.2m | 10m | 6 | 0.17mPa | 0.9m | 78.51 tons |
| 1.5m | 12m | 8 | 0.18mPa | 1.2m | 100.50 tons |
| 1.8m | 15m | 8 | 0.15mPa | 1.5m | 104.69 tons |
| 2.0m | 18m | 10 | 0.17mPa | 1.5m | 235.54 tons |
| 2.5m | 18m | 12 | 0.16mPa | 2.0m | 226.12 tons |
The Security issues of airbag usage
1.Super pressure control
To strictly control the working pressure, shall not exceed the stipulated in table 2 of the pressure of work
2. Spikes to avoid
The surface contact with airbag is not sharp outstanding person,prevent punctured.
3.Prevent distortion
The airbag in scrolling process avoid length direction generate distortion, Such as when the Catamarans ashore and down , if use done airbag easy to generate distortion. So please put two airbag in Catamarans below.
4.Exempt impact
Balloon inflated should avoid impact load. Especially in the ship fall pier, When the airbag as lifting has lifted most hull, To remove piers of wood and fill in scrolling the airbag process,if left one, two piers were still tightly, Don't touch it. Because the pier wood cut down, once the impact of hull gravity might make airbag burst. Should adjust the airbag pressure, Make leaving ship from piers of wood. And as with nothing in the process of moving ship collision, When will cause serious damage airbag.
5. Pressure test
Not long after the repair or airbag before revived, shall be carried out before reactivated no load charging test. Test pressure should take the pressure of work. Lab, inspector shall at least 3 meters away from the airbag. If after the repair damaged area, should reduce airbag pressure of work. Every year, all common airbag to the experiment,can ensure a safe use.
Why choose our marine airbags?
1. More than 20 years of production experience
2. Credible company to make airbags with optimzied rubber material and enough layers
3. Airbags have been inspected by Third-Party like BV, SGS, V-Trust etc
FAQ
."Can
I
use
marine
rubber
airbags
for
both
ship
launching
and
docking
?"
Answer:
Yes,
our
rubber
airbags
are
widely
used
for
ship
launching/
docking/
lifting/
moving
and
salvage
etc.now.
2.
"What's
the
advantage
of
your
marine
rubber
airbags
compared
to
slipway
?"
Answer:
1)
our
marine
rubber
airbags
are
much
cheaper
than
slipway,but
also
reusable,
it
can
save
money
and
labor
2)
our
marine
rubber
airbags
are
moveable
,
it
can
save
time
and
more
flexible
3)
our
rubber
airbags
are
much
soft
than
slipway,there's
no
harm
to
the
bottom
of
the
ship.
3.
"I
have
ships
but
don't
know
how
to
choose
rubber
airbags
size
,can
you
help
me?"
Answer:
Don't
worry
.We
have
more
than
20
years'
experience.
Pls
tell
me
information
of
your
ship,
we
can
suggest
suitable
size
for
you.
